Запчасти Komatsu WA250PT-3 ТРАНСМИССИЯ (1 И 3 МУФТА) СИЛОВАЯ ПЕРЕДАЧА

|$4

714-13-10001

TORQFLOW ASS'Y

SN: 50021-UP

1шт.

|$5

714-13-10000

TORQFLOW ASS'Y

SN: 50001-50020

1шт.

|$6

714-13-10041

TORQFLOW ASS'Y,(WITH EMERGENCY STEERING)

SN: 50021-UP

1шт.

|$7

714-13-10040

TORQFLOW ASS'Y,(WITH EMERGENCY STEERING)

SN: 50001-50020

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-70A0.

-1шт.

|$10

714-13-12020

CLUTCH ASS'Y,1ST AND 3RD

SN: 50001-UP

1шт.

|$11

714-13-12120

SHAFT ASS'Y

SN: 50001-UP

1шт.

1

0

SHAFT

SN: 50001-UP

1шт.

2

0

HOUSING ASS'Y

SN: 50001-UP

1шт.

3

714-13-12660

PISTON,1ST AND 3RD

SN: 50001-UP

2шт.

4

714-12-19711

DISC

SN: 50001-UP

8шт.

5

714-16-19730

PLATE,SEPARATE

SN: 50001-UP

10шт.

6

56D-15-12710

SPRING,WAVE

SN: 51017-UP

8шт.

6

0

SPRING,WAVE

SN: 50001-51016

8шт.

7

714-12-12610

PLATE,END

SN: 50001-UP

2шт.

8

419-15-12140

RING,SNAP

SN: 50001-UP

2шт.

9

714-16-19220

RING,SEAL

SN: 50001-UP

2шт.

10

714-16-19210

RING,SEAL

SN: 50001-UP

2шт.

11

714-08-19570

WASHER,THRUST

SN: 50001-UP

2шт.

12

714-08-19560

WASHER,THRUST

SN: 50001-UP

2шт.

13

419-15-12660

BEARING,NEEDLE

SN: 50001-UP

3шт.

14

714-12-12740

SPACER

SN: 50001-UP

1шт.

15

714-12-12720

SPACER

SN: 50001-UP

1шт.

16

714-12-19510

RING,SNAP

SN: 50001-UP

1шт.

17

714-13-12440

GEAR, 40 TEETH,3RD

SN: 50001-UP

1шт.

18

714-13-12430

GEAR, 21 TEETH,1ST

SN: 50001-UP

1шт.

19

714-13-12510

GEAR, 28 TEETH

SN: 50001-UP

1шт.

20

714-13-19340

BEARING,BALL

SN: 50001-UP

1шт.

21

06040-06211

BEARING

SN: 50001-UP

1шт.

22

419-15-12122

RING,SEAL

SN: 50001-UP

3шт.
