Запчасти Komatsu WA250-6 C-A ВЕНТИЛЯТОР РАДИАТОРА МОТОР (/) СИСТЕМА ОХЛАЖДЕНИЯ

|$0

708-7R-00700

MOTOR ASSEMBLY

SN: A76001--UP

1шт.

1

708-7R-11980

CASE

SN: A76001--UP

1шт.

2

07040-11007

PLUG

SN: A76001--UP

1шт.

3

07002-11023

O-RING

SN: A76001--UP

1шт.

|$4

708-7R-01680

COVER SUB ASSEMBLY

SN: A76001--UP

1шт.

4

NSS

COVER, END

SN: A76001--UP

1шт.

5

708-7R-11220

PLUG

SN: A76001--UP

2шт.

6

07002-11223

O-RING

SN: A76001--UP

2шт.

7

07040-11409

PLUG

SN: A76001--UP

1шт.

8

07002-11423

O-RING

SN: A76001--UP

1шт.

9

720-68-19610

PIN

SN: A76001--UP

2шт.

10

04065-01610

RING

SN: A76001--UP

1шт.

11

708-7R-18460

ORIFICE

SN: A76001--UP

1шт.

12

708-7R-03110

VALVE ASSEMBLY, RELIEF

SN: A76001--UP

1шт.

13

NSS

SPOOL

SN: A76001--UP

1шт.

14

NSS

PLUG

SN: A76001--UP

1шт.

15

NSS

O-RING

SN: A76001--UP

1шт.

16

708-7S-18120

SPRING

SN: A76001--UP

1шт.

17

708-7S-18130

SPACER

SN: A76001--UP

1шт.

18

NSS

SPOOL

SN: A76001--UP

1шт.

19

708-7R-18480

SPRING

SN: A76001--UP

1шт.

20

NSS

RETAINER

SN: A76001--UP

1шт.

21

NSS

ORIFICE

SN: A76001--UP

1шт.

22

708-7R-21110

PLUG

SN: A76001--UP

1шт.

23

07002-13334

O-RING

SN: A76001--UP

1шт.

24

708-7R-21120

SPRING

SN: A76001--UP

1шт.

|$26

26

-1шт.

|$27

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

27

-1шт.
