Запчасти Komatsu WA250-6 F-A HST РЕГУЛИР. НАСОС (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

PUMP, VARIABLE (SEE FIG. F2430-02A0 )

SN: A76001--UP

-1шт.

|$1

UC4020481906

VALVE HOUSING ASSEMBLY

SN: A76001--UP

1шт.

1

UC1020481826

HOUSING

SN: A76001--UP

1шт.

2

UC1020481871

CONTROL PISTON

SN: A76001--UP

1шт.

3

UC1020347322

COLLAR

SN: A76001--UP

2шт.

4

UC1700713621

SPRING

SN: A76001--UP

2шт.

5

UC1090830283

BOLT

SN: A76001--UP

4шт.

6

UC1090830219

BOLT

SN: A76001--UP

2шт.

7

UC1026007057

PLUG

SN: A76001--UP

4шт.

8

UC1701538797

PLUG

SN: A76001--UP

1шт.

9

UC1300082002

O-RING

SN: A76001--UP

1шт.

10

UC1300034003

O-RING

SN: A76001--UP

3шт.

11

UC1300030001

O-RING

SN: A76001--UP

1шт.

|$13

13

-1шт.

|$14

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

14

-1шт.
