Запчасти Komatsu WA250-6 F-9A HST РЕГУЛИР. НАСОС (8/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

PUMP, VARIABLE (SEE FIG. F2430-02A0 )

SN: A76001--UP

-1шт.

|$1

UC4704373637

VALVE, CUT-OFF

SN: A76001--UP

1шт.

1

UC1704365693

PLUG

SN: A76001--UP

1шт.

2

UC1704365538

BARREL

SN: A76001--UP

1шт.

3

UC1704321629

POPPET

SN: A76001--UP

1шт.

4

UC1704321639

PISTON

SN: A76001--UP

1шт.

5

UC1704321648

SPOOL

SN: A76001--UP

1шт.

6

UC1704362841

VALVE SEAT

SN: A76001--UP

1шт.

7

UC1720094027

SPRING

SN: A76001--UP

1шт.

8

UC1720430928

SPRING SEAT

SN: A76001--UP

2шт.

9

UC1704321675

SCREW

SN: A76001--UP

1шт.

10

UC1300142003

O-RING

SN: A76001--UP

1шт.

11

UC1701527072

NUT

SN: A76001--UP

1шт.

12

UC1300022009

O-RING

SN: A76001--UP

1шт.

|$14

14

-1шт.

|$15

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

15

-1шт.
