Запчасти Komatsu WA250-6 F-A HST РЕГУЛИР. НАСОС (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

PUMP, VARIABLE (SEE FIG. F2430-02A0 )

SN: A76001--UP

-1шт.

|$1

UC4020162421

HD CONTROL

SN: A76001--UP

1шт.

1

PISTON (SEE FIG. F2430-05A0 )

SN: A76001--UP

-1шт.

2

UC1720106212

COVER

SN: A76001--UP

1шт.

3

UC1720106221

COVER

SN: A76001--UP

1шт.

4

UC1701574775

NUT

SN: A76001--UP

1шт.

5

UC1301586009

BOLT

SN: A76001--UP

8шт.

6

UC1300297002

O-RING

SN: A76001--UP

2шт.

7

UC1726008389

RING

SN: A76001--UP

2шт.

8

UC1726002703

RING

SN: A76001--UP

2шт.

|$10

10

-1шт.

|$11

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

11

-1шт.
