Запчасти Komatsu WA250-6 F-A HST РЕГУЛИР. НАСОС (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

PUMP, VARIABLE (SEE FIG. F2430-02A0 )

SN: A76001--UP

-1шт.

|$1

UC4100516369

ROTARY GROUP

SN: A76001--UP

1шт.

1

UC4100663833

CYLINDER BLOCK

SN: A76001--UP

1шт.

2

UC4704145157

PISTON

SN: A76001--UP

9шт.

3

UC1709217287

SPRING

SN: A76001--UP

1шт.

4

UC1709222555

HANGER

SN: A76001--UP

1шт.

5

UC1704498106

GUIDE

SN: A76001--UP

1шт.

6

UC1099215509

SHAFT

SN: A76001--UP

1шт.

7

UC1704179593

PIN

SN: A76001--UP

2шт.

8

UC1709217296

RETAINER

SN: A76001--UP

1шт.

9

UC1709217306

GUIDE

SN: A76001--UP

1шт.

10

UC1020665932

BEARING

SN: A76001--UP

1шт.

11

UC1704498858

SHIM, 3.0 MM

SN: A76001--UP

2шт.

12

UC1704356497

SPRING

SN: A76001--UP

1шт.

13

UC1701531044

BEARING

SN: A76001--UP

1шт.

14

UC1708301657

BEARING

SN: A76001--UP

1шт.

15

UC1302133001

RING

SN: A76001--UP

1шт.

16

UC1726000019

WASHER

SN: A76001--UP

2шт.

17

UC1026018204

RING, SEAL

SN: A76001--UP

1шт.

18

UC1700845562

WASHER

SN: A76001--UP

1шт.

19

UC1704329835

SHIM, 1.2 MM

SN: A76001--UP

1шт.

|$21

UC1704329844

SHIM, 1.0 MM

SN: A76001--UP

1шт.

|$22

UC1704329853

SHIM, 0.8 MM

SN: A76001--UP

1шт.

|$23

UC1704329862

SHIM, 0.6 MM

SN: A76001--UP

1шт.

|$24

24

-1шт.

|$25

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

25

-1шт.
