Запчасти Komatsu WA250-6 HST НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$$1

PARTS MARKED B4, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B4.

-1шт.

|$$2

PARTS MARKED B5, CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B5.

-1шт.

|$3

418-18-31101

PUMP

SN: 75001-UP

1шт.

|$4

UC4100656147

COVER

SN: 75001-UP

1шт.

1

0

RELIEF VALVE

SN: 75001-UP

2шт.

2

0

RELIEF VALVE

SN: 75001-UP

1шт.

3

0

CUT-OFF VALVE

SN: 75001-UP

1шт.

4

UC1100656159

COVER B4

SN: 75001-UP

1шт.

5

UC1704491361

METAL B4

SN: 75001-UP

1шт.

6

UC1301638009

BOLT

SN: 75001-UP

4шт.

7

UC1303046816

O-RING

SN: 75001-UP

1шт.

8

UC1701539213

PLUG B4

SN: 75001-UP

1шт.

9

UC1300038005

O-RING

SN: 75001-UP

1шт.

10

0

PLUG

SN: 75001-UP

2шт.

11

UC1701516926

PLUG

SN: 75001-UP

1шт.

12

UC1704405379

BUSHING B5

SN: 75001-UP

1шт.

13

UC1704357904

METAL B5

SN: 75001-UP

1шт.

14

UC1701538807

PLUG B4

SN: 75001-UP

2шт.
