Запчасти Komatsu WA250-5L ТАБЛИЧКИ (АНГЛ.) МАРКИРОВКА

1

418-93-22211

PLATE,L.H.

SN: A73001-UP

1шт.

2

418-93-22221

PLATE,R.H.

SN: A73001-UP

1шт.

3

09690-P0800

PLATE, MARK,KOMATSU

SN: A73001-UP

2шт.

4

418-93-22232

OIL CHART

SN: A73001-UP

1шт.

5

09960-01601

PLATE, MARK,LIFT HERE

SN: A73001-UP

4шт.

|$6

418-93-22240

PLATE

SN: A73001-UP

1шт.

6

0

PLATE,REAR AXLE

SN: A73001-UP

1шт.

7

0

PLATE,RADIATOR DRAIN

SN: A73001-UP

1шт.

8

0

PLATE,CYLINDER

SN: A73001-UP

1шт.

9

09669-0000E

PLATE, CAUTION,DIESEL FUEL

SN: A73001-UP

1шт.

10

09161-23000

PLATE,GRILLE SIDE

SN: A73001-UP

1шт.

11

09653-03001

PLATE, SAFETY,HYDRAULIC TANK CAP

SN: A73001-UP

1шт.

12

09162-23000

PLATE,GRILLE BOTTOM

SN: A73001-UP

2шт.

13

09807-C0883

PLATE, SAFETY,KEEP OUT

SN: A73001-UP

2шт.

14

09667-03001

PLATE, SAFETY,FAN

SN: A73001-UP

2шт.

15

09812-13000

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: A73001-UP

2шт.

16

09808-03000

PLATE, SAFETY,BATTERY

SN: A73001-UP

2шт.

17

09668-03001

PLATE, SAFETY

SN: A73001-UP

1шт.

18

0

PLATE

SN: A73001-UP

1шт.

19

04418-13060

SCREW

SN: A73001-UP

4шт.

20

421-93-A1510

PLATE

SN: A73001-UP

1шт.

21

09963-03001

TAG

SN: A73001-UP

1шт.

22

418-93-A2410

PLATE, CAUTION,GRILLE

SN: A73001-UP

4шт.
