Запчасти Komatsu WA250-3MC A9-AA ГЕНЕРАТОР SI - V - AMP ДВИГАТЕЛЬ

|$0

6743-82-6140

ALTERNATOR, PRODUCTION

1шт.

|$1

1286 822 H91

ALTERNATOR, SERVICE

1шт.

1

1268 345 H1

HOUSING, RECTIFIER

1шт.

2

1268 346 H91

ROTOR ASSEMBLY

1шт.

3

1268 347 H91

STATOR ASSEMBLY

1шт.

4

1268 348 H1

FRAME

1шт.

5

1268 349 H91

RECTIFIER BRIDGE

1шт.

6

1268 350 H1

DIODE TRIO

1шт.

7

1268 351 H91

FIELD COIL AND SUPPORT ASSEMBLY

1шт.

8

1268 352 H1

COVER, END

1шт.

9

1218 115 H1

REGULATOR AND RESISTOR ASSEMBLY

1шт.

10

1268 354 H1

CONNECTOR, OUTPUT TERMINAL

1шт.

11

1268 355 H1

CONNECTOR, RELAY TERMINAL

1шт.

12

1268 356 H1

CONNECTOR, REGULATOR

1шт.

13

1268 357 H91

PACKAGE, OUTPUT TERMINAL

1шт.

14

1268 358 H91

PACKAGE, RELAY TERMINAL

1шт.

15

1268 359 H1

CAPACITOR

1шт.

16

98 819

BRACKET, CAPACITOR MOUNTING

1шт.

17

1218 121 H1

PLATE, RETAINER - INSIDE

1шт.

18

1268 360 H1

PLATE, RETAINER - OUTSIDE

1шт.

19

1213 268 H1

BEARING, BALL

1шт.

20

1268 361 H1

COLLAR - INSIDE

1шт.

21

1218 123 H1

COLLAR - OUTSIDE

1шт.

22

1268 362 H91

FAN AND BAFFLE ASSEMBLY

1шт.

23

1218 126 H1

NUT, CONNECTOR

1шт.

24

1218 126 H1

NUT, TERMINAL STUD

1шт.

25

19 830 R1

NUT, SHAFT

1шт.

26

1268 363 H1

SCREW, MOUNTING

3шт.

27

1268 364 H1

SCREW ASSEMBLY, MOUNTING

2шт.

28

1268 363 H1

SCREW, MOUNTING

5шт.

29

1213 252 H1

SCREW, ATTACHING

4шт.

30

1268 365 H1

SCREW AND WASHER ASSEMBLY, MOUNTING

1шт.

31

1268 366 H1

SCREW ASSEMBLY, MOUNTING

1шт.

32

1268 367 H1

SCREW ASSEMBLY, ATTACHING

1шт.

33

1268 365 H1

SCREW AND WASHER ASSEMBLY, MOUNTING

1шт.

34

1268 368 H1

WASHER, FELT

1шт.

35

88 803

WASHER, FELT

1шт.

36

1268 369 H1

WASHER

1шт.

37

1268 370 H1

WASHER, SHAFT

1шт.

38

389 603 C91

BEARING, RECTIFIER HOUSING

1шт.

39

1268 371 H1

BOLT, THRU

4шт.

40

1213 242 H1

BUSHING, PIVOT

1шт.

41

1268 372 H1

BUSHING, MOUNTING SCREW

1шт.

42

1213 274 H1

CAP, RELAY TERMINAL

1шт.

43

1268 373 H1

CUP, FELT WASHER

1шт.

44

1268 374 H1

GROMMET

1шт.

45

1268 375 H1

INSULATOR

1шт.

46

1218 131 H1

SHIELD, BEARING RETAINER PLATE

1шт.

|$48

48

-1шт.

|$49

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER THE SER VICE ALTERNATOR.

49

-1шт.
