Запчасти Komatsu WA250-3MC U-A МАРКИРОВКА ФРАНЦИЯ МАРКИРОВКА

|$0

417-933-A170

PLATE KIT

SN: A71001 --UP

1шт.

1

NSS

PLATE, SAFETY - KEEP OUT

SN: A71001 --UP

2шт.

2

NSS

PLATE, SAFETY - SAFETY BAR

SN: A71001 --UP

1шт.

3

NSS

PLATE, INSTRUCTION - FUEL

SN: A71001 --UP

1шт.

4

NSS

PLATE, SAFETY - RADIATOR CAP

SN: A71001 --UP

1шт.

5

NSS

PLATE, INSTRUCTION - ENGINE OIL

SN: A71001 --UP

1шт.

6

NSS

PLATE, CAUTION - BRAKE OIL

SN: A71001 --UP

1шт.

7

NSS

PLATE, SAFETY - HYDRAULIC TANK CAP

SN: A71001 --UP

1шт.

8

NSS

PLATE, CAUTION - BATTERY CABLE

SN: A71001 --UP

1шт.

9

417-93-21141

PLATE, MARK - KOMATSU

SN: A71001 --UP

1шт.

10

417-93-21150

PLATE, STRIPE - L.H.

SN: A71001 --UP

1шт.

11

417-93-21160

PLATE, STRIPE - R.H.

SN: A71001 --UP

1шт.

12

418-93-21220

PLATE, MARK WA250

SN: A71001 --UP

2шт.

13

09812-15000

PLATE, SAFETY

SN: A71001 --UP

2шт.

14

418-93-32130

CHART, OIL

SN: A71001 --UP

1шт.

15

418-93-A2320

PLATE, MARK - AVANCE LOADER

SN: A71001 --UP

2шт.

16

418-93-A2340

DECAL, PLUS - HOOD

SN: A71001 --UP

2шт.

17

09690-D0800

DECAL, KOMATSU - BOOM

SN: A71001 --UP

2шт.

18

09960-01001

PLATE, MARK HANDLING - LIFT HERE

SN: A71001 --UP

4шт.

19

09812-15000

PLATE, SAFETY

SN: A71001 --UP

2шт.

20

419-93-A2310

DECAL, REAR WINDOW

SN: A71001 --UP

1шт.

21

418-93-A2330

DECAL, FRONT WINDOW

SN: A71001 --UP

1шт.

22

09667-05001

PLATE, SAFETY - FAN

SN: A71001 --UP

2шт.

23

09690-C0450

DECAL, KOMATSU

SN: A71001 --UP

2шт.

24

419-933-A150

DECAL, BATTERY BOOST

SN: A71001 --UP

1шт.

25

7823-92-9063

PLATE, MANUAL

SN: A71001 --UP

4шт.

26

417-931-A190

DECAL, ALARM

SN: A71001 --UP

1шт.

N/I

419-93-A1510

DECAL, MADE IN CANADA

SN: A71001 --UP

1шт.

N/I

1170 725 C2

DECAL, EMERGENCY EXIT (ON WINDOW SILL)

SN: A71001 --UP

1шт.
