Запчасти Komatsu WA250-3MC U-A МАРКИРОВКА АНГЛ. МАРКИРОВКА

|$0

417-93-21310

PLATE KIT

SN: A71001 --UP

1шт.

1

NSS

PLATE, SAFETY, KEEP OUT

SN: A71001 --UP

2шт.

2

NSS

PLATE, SAFETY, SAFETY BAR

SN: A71001 --UP

1шт.

3

NSS

PLATE, INSTRUCTION, FUEL

SN: A71001 --UP

1шт.

4

NSS

PLATE, SAFETY, RADIATOR CAP

SN: A71001 --UP

1шт.

5

NSS

PLATE, INSTRUCTION, ENGINE OIL

SN: A71001 --UP

1шт.

6

NSS

PLATE, CAUTION, BRAKE OIL

SN: A71001 --UP

1шт.

7

NSS

PLATE, SAFETY, HYDRAULIC TANK CAP

SN: A71001 --UP

1шт.

8

NSS

PLATE, CAUTION, BATTERY CABLE

SN: A71001 --UP

1шт.

9

417-93-21141

PLATE, MARK, KOMATSU

SN: A71001 --UP

1шт.

10

417-93-21150

PLATE, L.H. STRIPE

SN: A71001 --UP

1шт.

11

417-93-21160

PLATE, R.H. STRIPE

SN: A71001 --UP

1шт.

12

418-93-21220

PLATE, MARK WA250

SN: A71001 --UP

2шт.

13

09807-C0880

PLATE, SAFETY - LIFT ARM

SN: A71001 --UP

2шт.

14

418-93-21250

CHART, OIL

SN: A71001 --UP

1шт.

15

418-93-A2320

PLATE, MARK, AVANCE LOADER

SN: A71001 --UP

2шт.

16

418-93-A2340

DECAL, PLUS, HOOD

SN: A71001 --UP

2шт.

17

09690-D0800

DECAL, KOMATSU, BOOM

SN: A71001 --UP

2шт.

18

09960-01001

PLATE, MARK HANDLING, LIFT HERE

SN: A71001 --UP

4шт.

19

09812-13000

PLATE, SAFETY

SN: A71001 --UP

2шт.

20

419-93-A2310

DECAL, REAR WINDOW

SN: A71001 --UP

1шт.

21

418-93-A2330

DECAL, FRONT WINDOW

SN: A71001 --UP

1шт.

22

09667-03001

PLATE, SAFETY, FAN

SN: A71001 --UP

2шт.

23

09690-C0450

DECAL, KOMATSU

SN: A71001 --UP

2шт.

24

419-93-A2130

DECAL, BATTERY BOOST

SN: A71001 --UP

1шт.

25

7823-62-9063

PLATE, MANUAL

SN: A71001 --UP

4шт.

26

419-93-A2150

DECAL, DOOR LOCKED

SN: A71001 --UP

1шт.

27

417-931-A180

DECAL, ALARM

SN: A71001 --UP

1шт.

28

416-93-A1410

PLATE

SN: A71001 --UP

1шт.

N/I

418-93-A1250

DECAL, WARNING, DOWNHILL TRAVEL

SN: A71001 --UP

1шт.

N/I

419-93-A1510

DECAL, MADE IN CANADA

SN: A71001 --UP

1шт.

N/I

418-U77-A820

DECAL, CHECK COUPLER LOCK

SN: A71001 --UP

1шт.

N/I

09685-00002

DECAL, SAFETY LEVER LOCK-UNLOCK

SN: A71001 --UP

1шт.

N/I

1170 724 C2

DECAL, EMERGENCY EXIT (ON WINDOW SILL)

SN: A71001 --UP

1шт.
