Запчасти Komatsu WA250-3MC K7-A ОБОГРЕВАТЕЛЬ./КОНДИЦ. ВОЗДУХА НАГНЕТАТЕЛЬ ASSEMBLY OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

HEATER UNIT (SEE FIG. K0710-01A0 )

SN: A71001--UP

-1шт.

|$19

OR

1

-1шт.

|$2

AIR CONDITIONER UNIT (SEE FIG. K0710-01A2 )

SN: A71001--UP

-1шт.

|$3

ND116300-4630

BLOWER ASSEMBLY

SN: A71001--UP

1шт.

1

ND116251-9192

CASE

SN: A71001--UP

1шт.

2

ND146638-9460

PACKING

SN: A71001--UP

1шт.

3

ND116290-0321

SUB ASSEMBLY

SN: A71001--UP

1шт.

4

ND915700-5121

SCREW, TAPPING

SN: A71001--UP

8шт.

5

ND146622-6880

PACKING

SN: A71001--UP

1шт.

6

ND116340-2361

MOTOR ASSEMBLY (WITH FAN)

SN: A71001--UP

1шт.

|$10

ND116221-0960

FAN, BLOWER

SN: A71001--UP

1шт.

|$11

ND017231-2370

CLAMP

SN: A71001--UP

1шт.

7

ND116471-6630

BRACKET, CASE

SN: A71001--UP

1шт.

8

ND914780-5168

BOLT, WITH WASHER

SN: A71001--UP

3шт.

9

ND909300-6141

SCREW, TAPPING

SN: A71001--UP

3шт.

10

ND146810-9062

RESISTOR, BLOWER

SN: A71001--UP

1шт.

11

ND909300-4121

SCREW, TAPPING

SN: A71001--UP

2шт.

12

ND146651-1840

PIPE

SN: A71001--UP

1шт.

13

ND146691-1360

CLAMP

SN: A71001--UP

1шт.
