Запчасти Komatsu WA250-3MC A-AA ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

|$0

6737-32-3120

ENGINE ROD ASSEMBLY

6шт.

1

NSS

ROD, ENGINE CONNECTING

1шт.

2

6732-31-3320

BOLT, CONNECTING ROD CAP

2шт.

3

6732-31-3132

BUSHING

1шт.

4

6732-31-3420

BEARING, CONNECTING ROD LOWER (STD)

6шт.

5

6732-31-3411

BEARING, CONNECTING ROD UPPER (STD)

6шт.

|$6

6738-32-2040

KIT, ENGINE PISTON (STD)

6шт.

6

NSS

PISTON, ENGINE

1шт.

7

6732-31-2420

RING, RETAINING

2шт.

8

6738-31-2030

SET, PISTON RING

1шт.

9

6731-31-2410

PIN, PISTON

6шт.

|$28

SERVICE PARTS

11

-1шт.

4

6738-39-3400

BEARING, CONNECTING ROD (0.25MM OS)

-2шт.

4

6738-38-3400

BEARING, CONNECTING ROD (0.50MM OS)

-2шт.

4

6738-37-3400

BEARING, CONNECTING ROD (0.75MM OS)

-2шт.

4

6738-36-3400

BEARING, CONNECTING ROD (1.00MM OS)

-2шт.

5

6736-39-3400

BEARING, CONNECTING ROD (0.25MM OS)

-2шт.

5

6736-38-3400

BEARING, CONNECTING ROD (0.50MM OS)

-2шт.

5

6736-37-3400

BEARING, CONNECTING ROD (0.75MM OS)

-2шт.

5

6736-36-3400

BEARING, CONNECTING ROD (1.00MM OS)

-2шт.

|$20

6735-39-2210

KIT, ENGINE PISTON (0.50MM OS)

-2шт.

6

NSS

PISTON, ENGINE

1шт.

7

6732-31-2420

RING, RETAINING

2шт.

8

6738-39-2030

SET, PISTON RING

1шт.

|$24

6735-38-2210

KIT, ENGINE PISTON (1.00MM OS)

-2шт.

6

NSS

PISTON, ENGINE

1шт.

7

6732-31-2420

RING, RETAINING

2шт.

8

6732-38-2300

SET, PISTON RING

1шт.
