Запчасти Komatsu WA250-3L FIG. C-A РАДИАТОР - ТРУБЫ СИСТЕМА ОХЛАЖДЕНИЯ

1

417-03-A1430

HOSE, CONNECTION - INLET TUBE BOTHENDS

SN: A70001-UP-UP

2шт.

2

418-03-A1361

TUBE - RADIATOR INLET

SN: A70001-UP-UP

1шт.

3

07281-00609

CLAMP

SN: A70001-UP-UP

4шт.

4

417-03-A1450

HOSE

SN: A70001-UP-UP

2шт.

5

07281-00709

CLAMP

SN: A70001-UP-UP

4шт.

6

418-03-A1371

TUBE - RADIATOR OUTLET

SN: A70001-UP-UP

1шт.

7

07260-20927

HOSE, LOW-PRESSURE

SN: A70001-UP-UP

1шт.

8

433 044 C1

NIPPLE, HOSE

SN: A70001-UP-UP

1шт.

9

07281-00197

CLAMP

SN: A70001-UP-UP

2шт.

10

434 536 C1

FITTING, HOSE

SN: A70001-UP-UP

1шт.

11

864 458 R1

ELBOW, HOSE

SN: A70001-UP-UP

1шт.

12

07281-00259

CLAMP

SN: A70001-UP-UP

2шт.

13

HOSE - 63 IN.

SN: A70001-UP-UP

-2шт.

14

01010-81016

BOLT

SN: A70001-UP-UP

1шт.

15

299 567 C1

CLIP

SN: A70001-UP-UP

2шт.

16

COCK, DRAIN (SEE FIG. C0110-01A0)

SN: A70001-UP-UP

-1шт.

17

HOSE, DRAIN COCK (SEE FIG. C0110-01A0)

SN: A70001-UP-UP

-1шт.

18

HOSE, OVERFLOW (SEE FIG. M4100-03A0)

SN: A70001-UP-UP

-1шт.

|$18

364 359 C1

HOSE, BULK

SN: A70001-UP-UP

-2шт.

|$19

-1шт.

|$20

F1 - SEE PARTS AND SERVICE NEWS AA00062 FOR ADDITIONAL INFORMATION.F2 - CUT TO FIT FROM BULK HOSE.

-1шт.

|$21

-1шт.

|$22

-1шт.

|$23

F1 - SEE PARTS AND SERVICE NEWS AA00062 FOR ADDITIONAL INFORMATION.F2 - CUT TO FIT FROM BULK HOSE.

-1шт.

|$24

-1шт.
