Запчасти Komatsu WA250-3L FIG. B-A СТАРТЕР - V - . KW - CURRENT ВЕРСИЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

6731-82-6510

MOTOR, STARTING

1шт.

1

ND0281002882

YOKE, STARTER

1шт.

2

ND0280620130

COVER

1шт.

3

ND0280993570

STARTER KIT - BRUSH (+)

2шт.

4

ND0282001590

ARMATURE, STARTER

1шт.

5

ND9491001930

BEARING BALL - OD35

1шт.

6

ND9491001750

BEARING BALL - OD30

1шт.

|$7

ND0283006551

CLUTCH SUB-ASSEMBLY, STARTER

1шт.

|$8

ND0280993270

STARTER KIT - PINION KIT

1шт.

7

NSS

SPRING

1шт.

8

NSS

COLLAR

1шт.

9

NSS

RING, SNAP

2шт.

10

NSS

GEAR, PINION

1шт.

11

NSS

BEARING

1шт.

12

ND0283006750

CLUTCH SUB-ASSEMBLY, STARTER - CLUTCH KIT

1шт.

13

ND4941004501

BEARING, BALL - OD47

1шт.

14

ND9491001920

BEARING, BALL - OD47

1шт.

15

ND9491704040

SPRING, COMPRESSION COIL

1шт.

16

ND0283810071

SHAFT

1шт.

17

ND2284010633

HOUSING, STARTER

1шт.

18

ND1534006161

SWITCH ASSEMBLY, MAGNETIC

1шт.

19

ND1280995830

STARTER KIT - TERMINAL KIT M

1шт.

20

ND0280993160

STARTER KIT - TERMINAL KIT C

1шт.

21

ND0536600443

PLUNGER SUB-ASSEMBLY

1шт.

22

ND0534040240

GASKET, SWITCH - A

1шт.

23

ND0535050290

COVER, SOLENOID

1шт.

24

ND0280650250

BUSHING, DRAIN

1шт.

25

ND9490474440

BOLT WITH WASHER - M5, L14

3шт.

26

ND0285105390

HOLDER ASSEMBLY, STARTER BRUSH

1шт.

27

ND9491730571

SPRING, BRUSH SPIRAL

4шт.

28

ND1285010120

FRAME, STARTER END

1шт.

29

ND1289610010

BALL, STARTER

1шт.

30

ND9491704070

SPRING, COMPRESSION COIL

1шт.

31

ND0283711500

PINION, STARTER

1шт.

32

ND0283060070

ROLLER, CLUTCH

5шт.

33

ND0280630030

RETAINER

1шт.

34

ND0283270171

RETAINER, SNAP

1шт.

35

ND1289500520

BOLT, STARTER - M6, L182

2шт.

36

ND9490076530

SCREW WITH WASHER - M5, L9.4

2шт.

37

ND9017010061

NUT, HEXAGON - FOR TERMINAL M

2шт.

38

ND9490064720

SCREW - M6, L50

3шт.

39

ND9490200600

WASHER, FELT - T3

1шт.

40

ND9025810001

WASHER, SPRING - FOR TERMINAL M

2шт.

41

ND9490076850

SCREW WITH WASHER - M5, L8

1шт.

42

ND9020006241

WASHER, PLATE - T1

3шт.

43

ND0280625790

COVER

1шт.

44

ND9080110050

O-RING - ID4.8

3шт.

45

ND0289015190

SEAL, STARTER

1шт.

46

ND9490564480

NUT - FOR TERMINAL C

1шт.
