Запчасти Komatsu WA250-3L FIG. U-A МАРКИРОВКА - ФРАНЦИЯ МАРКИРОВКА

|$0

417-93-32110

PLATE KIT

SN: A70001-UP-UP

1шт.

1

NSS

PLATE, SAFETY - KEEP OUT

SN: A70001-UP-UP

2шт.

2

NSS

PLATE, SAFETY - SAFETY BAR

SN: A70001-UP-UP

1шт.

3

NSS

PLATE, INSTRUCTION - FUEL

SN: A70001-UP-UP

1шт.

4

NSS

PLATE, SAFETY - RADIATOR CAP

SN: A70001-UP-UP

1шт.

5

NSS

PLATE, INSTRUCTION - ENGINE OIL

SN: A70001-UP-UP

1шт.

6

NSS

PLATE, SAFETY - BRAKE OIL

SN: A70001-UP-UP

1шт.

7

NSS

PLATE, SAFETY - HYDRAULIC TANK CAP

SN: A70001-UP-UP

1шт.

8

NSS

PLATE, SAFETY - BATTERY CABLE

SN: A70001-UP-UP

1шт.

9

417-93-21141

PLATE, MARK - KOMATSU

SN: A70001-UP-UP

1шт.

10

417-93-21150

PLATE, STRIPE - L.H.

SN: A70001-UP-UP

1шт.

11

417-93-21160

PLATE, STRIPE - R.H.

SN: A70001-UP-UP

1шт.

12

418-93-21220

PLATE, MARK - WA250

SN: A70001-UP-UP

2шт.

13

417-93-21220

PLATE, MARK - ADVANCE LOADER

SN: A70001-UP-UP

2шт.

14

418-93-32130

CHART, OIL

SN: A70001-UP-UP

1шт.

15

09806-C0883

PLATE, CAUTION - KEEP A SAFE DISTANCE

SN: A70001-UP-UP

2шт.

16

09667-A0880

PLATE, SAFETY - FAN

SN: A70001-UP-UP

2шт.

17

09807-C0883

PLATE, SAFETY - KEEP OUT

SN: A70001-UP-UP

2шт.

18

09960-01001

PLATE, MARK - LIFT HERE

SN: A70001-UP-UP

4шт.

19

09690-C0450

PRODUCT GRAPHIC - KOMATSU

SN: A70001-UP-UP

2шт.

N/I

1170 725 C2

PRODUCT GRAPHIC - EMERGENCY EXIT

SN: A70001-UP-UP

1шт.

20

7823-62-9062

PLATE - E.C.S.S. EMERGENCY STEERINGMANUAL AND AUTO GREASE

SN: A70001-UP-UP

1шт.

N/I

1310 307 H1

PRODUCT GRAPHIC - NO ETHER

SN: A70001-UP-UP

1шт.
