Запчасти Komatsu WA250-3L FIG. K7-7A КОНДИЦ. ВОЗДУХА И ОБОГРЕВАТЕЛЬ. - ТРУБЫ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

AIR CONDITIONER KIT(SEE FIG. K0710-01A0)

SN: A70001-UP-UP

-1шт.

|$2

OR

-1шт.

|$4

HEATER ASSEMBLY (SEE FIG. K0710-01A1)

SN: A70001-UP-UP

-1шт.

|$5

1312 034 H91

KIT, SOLENOID VALVE

SN: A70311-UP-UP

1шт.

1

425-963-AB80

O-RING

SN: A70311-UP-UP

2шт.

2

419-963-AC90

FITTING, STR

SN: A70311-UP-UP

1шт.

3

1434 665 H1

CLIP, CLOSED

SN: A70311-UP-UP

5шт.

4

1431 254 H1

ELBOW, HOSE

SN: A70311-UP-UP

1шт.

5

417-963-A670

BRACKET

SN: A70311-UP-UP

1шт.

6

30 019 R1

SCREW

SN: A70311-UP-UP

1шт.

7

419-963-AC60

VALVE, WATER - CURRENT VERSION

SN: A70311-UP-UP

1шт.

8

20Y-979-A840

SCREW

SN: A70311-UP-UP

2шт.

9

419-963-AC80

ADAPTER

SN: A70311-UP-UP

1шт.

10

HOSE, INLET - 18.75 IN.

SN: A70311-UP-UP

1шт.

11

HOSE, INLET - 14.50 IN.

SN: A70311-UP-UP

1шт.

12

419-963-AD70

BRACKET, RELAY

SN: A70311-UP-UP

1шт.

13

419-963-AD50

RELAY

SN: A70311-UP-UP

1шт.

N/I

426-942-A210

SCREW, LOCK - NO. 10 NC X 1/2 IN.

SN: A70311-UP-UP

1шт.

N/I

TIES, NYLON (SEE FIG. K0710-05A0)

SN: A70311-UP-UP

-1шт.

N/I

WIRING HARNESS (SEE FIG. K0710-05A0)

SN: A70311-UP-UP

-1шт.

|$22

364 360 C1

HOSE, BULK

SN: A70311-UP-UP

-2шт.

|$23

-1шт.

|$24

F1 - SEE PARTS AND SERVICE NEWS AA98123 AND AA99105 FOR INSTALLATIONINSTRUCTIONS.

-1шт.

|$26

-1шт.

|$27

F2 - CUT TO FIT FROM BULK HOSE.

-1шт.

|$28

-1шт.
