Запчасти Komatsu WA250-3L FIG. K7-A ОБОГРЕВАТЕЛЬ. - ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

418-942-A400

HEATER ASSEMBLY

SN: A70001-UP-UP

1шт.

1

BOX, AIR FILTER (SEE FIG. K0710-02A0)

SN: A70001-UP-UP

-1шт.

2

BOX, FAN (SEE FIG. K0710-03A0)

SN: A70001-UP-UP

-1шт.

|$3

REAR CONSOLE (SEE FIG. K0715-01A0)

SN: A70001-UP-UP

-1шт.

|$4

419-942-A510

A/C AND HEATER HARDWARE KIT

SN: A70001-UP-UP

1шт.

3

HEATER COIL (SEE FIG. K0710-04A1)

SN: A70001-UP-UP

-1шт.

|$6

ELECTRICAL WIRING, HEATER (SEE FIG. K0710-05A0)

SN: A70001-UP-UP

-1шт.

|$7

HEATER PIPING (SEE FIG. K0710-07A1)

SN: A70311-UP-UP

-1шт.

|$8

CONTROLLER (SEE FIG. K0710-08A0)

SN: A70001-UP-UP

-1шт.

N/I

419-963-A320

DUCT KIT

SN: A70001-UP-UP

1шт.

|$10

419-963-AC10

HOSE, FLEX

SN: A70001-UP-UP

1шт.

|$11

419-963-AC20

HOSE, FLEX

SN: A70001-UP-UP

1шт.

|$12

419-963-AC30

HOSE, FLEX

SN: A70001-UP-UP

1шт.

|$13

-1шт.

|$14

F1 - A/C AND HEATER HARDWARE KIT REPLACED BY P/N 1312 034 H91 VALVE KITS/N A70311-UP. (SEE FIG. K0710-07A1) TO VIEW VALVE KIT.

-1шт.

|$15

-1шт.
