Запчасти Komatsu WA250-3L FIG. H-A GROUND ПРИВОДN РУЛЕВ. УПРАВЛЕНИЕ - НАСОС ASSEMBLY ГИДРАВЛИКА

|$0

704-30-29110

PUMP ASSEMBLY

SN: A70001-UP-UP

1шт.

1

704-37-02030

BRACKET

SN: A70001-UP-UP

1шт.

2

704-37-29010

CASE, GEAR

SN: A70001-UP-UP

1шт.

3

704-37-02180

COVER

SN: A70001-UP-UP

1шт.

4

705-17-29411

GEAR, DRIVE

SN: A70001-UP-UP

1шт.

5

705-17-29512

GEAR, DRIVEN

SN: A70001-UP-UP

1шт.

6

704-37-02350

BEARING, NEEDLE

SN: A70001-UP-UP

4шт.

7

704-37-02610

PLATE, SIDE

SN: A70001-UP-UP

2шт.

8

704-37-02440

RING, BACK-UP

SN: A70001-UP-UP

4шт.

9

704-37-02470

RING, SEAL

SN: A70001-UP-UP

4шт.

10

704-37-02450

RING, BACK-UP

SN: A70001-UP-UP

4шт.

11

07000-12100

O-RING

SN: A70001-UP-UP

2шт.

12

04020-01024

PIN, DOWEL

SN: A70001-UP-UP

4шт.

13

01252-31485

BOLT

SN: A70001-UP-UP

4шт.

14

705-17-04980

WASHER, SPRING

SN: A70001-UP-UP

4шт.

15

705-17-02830

SEAL, OIL

SN: A70001-UP-UP

1шт.

16

04065-04018

RING, SNAP

SN: A70001-UP-UP

1шт.

|$17

-1шт.

|$18

F1 - PARTS SUPPLIED SEPARATELY ONLY TO DESIGNATED DEALERS EQUIPPED WITH A HYDRAULIC PUMP TESTER.

-1шт.

|$19

-1шт.
