Запчасти Komatsu WA250-3L FIG. H-A ГИДРАВЛS - ТРУБЫ - ЛИНИЯ ПОДАЧИ ГИДРАВЛИКА

1

07000-13025

O-RING

SN: A70001-UP-UP

1шт.

2

418-62-23910

HOSE - WITHOUT GROUND DRIVEN STEERING

SN: A70001-UP-UP

1шт.

3

418-62-11620

O-RING

SN: A70001-UP-UP

1шт.

4

07371-30638

FLANGE, SPLIT - WITHOUT GROUND DRIVEN STEERING

SN: A70001-UP-UP

2шт.

5

01010-80885

BOLT - WITH GROUND DRIVEN STEERING

SN: A70001-UP-UP

4шт.

6

01643-50823

WASHER - WITH GROUND DRIVEN STEERING

SN: A70001-UP-UP

4шт.

7

07000-13032

O-RING - WITHOUT GROUND DRIVENSTEERING

SN: A70001-UP-UP

1шт.

8

07371-31049

FLANGE, SPLIT - WITHOUT GROUND DRIVEN STEERING

SN: A70001-UP-UP

2шт.

9

07372-21035

BOLT - WITHOUT GROUND DRIVENSTEERING

SN: A70001-UP-UP

4шт.

10

01643-51032

WASHER - WITHOUT GROUND DRIVENSTEERING

SN: A70001-UP-UP

4шт.

11

418-62-23920

BLOCK

SN: A70001-UP-UP

1шт.

12

07122-01005

HOSE

SN: A70001-UP-UP

1шт.

13

07000-13032

O-RING

SN: A70001-UP-UP

2шт.

14

07371-31049

FLANGE, SPLIT

SN: A70001-UP-UP

4шт.

15

07372-21030

BOLT

SN: A70001-UP-UP

8шт.

16

01643-51032

WASHER

SN: A70001-UP-UP

8шт.

17

07042-20108

PLUG

SN: A70001-UP-UP

1шт.

18

418-62-23960

FLANGE

SN: A70001-UP-UP

1шт.

19

421-62-23350

CUSHION

SN: A70001-UP-UP

2шт.

20

421-62-23710

CUSHION

SN: A70001-UP-UP

2шт.

21

175-54-34170

WASHER

SN: A70001-UP-UP

4шт.

22

01435-01035

BOLT

SN: A70001-UP-UP

2шт.

23

07373-10600

SPACER - WITH GROUND DRIVEN STEERING

SN: A70001-UP-UP

1шт.

24

07000-13025

O-RING

SN: A70001-UP-UP

1шт.

25

418-62-23950

HOSE - EARLIER VERSION

1шт.

|$26

OR

-1шт.

25

418-62-A1620

HOSE - CURRENT VERSION

1шт.

26

07000-13025

O-RING

SN: A70001-UP-UP

1шт.

27

07371-30638

FLANGE, SPLIT

SN: A70001-UP-UP

2шт.

28

01010-80840

BOLT - WITHOUT GROUND DRIVEN STEERING

SN: A70001-UP-UP

4шт.

29

01643-50823

WASHER - WITHOUT GROUND DRIVENSTEERING

SN: A70001-UP-UP

4шт.

30

415-62-13710

PROTECTOR

SN: A70001-UP-UP

1шт.

31

418-62-11411

UNION - WITH GROUND DRIVEN STEERING

SN: A70001-UP-UP

1шт.

32

876 107 C2

O-RING - WITH GROUND DRIVEN STEERING

SN: A70001-UP-UP

1шт.

N/I

01435-01016

BOLT - WITH GROUND DRIVEN STEERING

SN: A70001-UP-UP

2шт.

33

TUBE (SEE FIG. H0122-04A0)

SN: A70001-UP-UP

-1шт.

|$38

-1шт.

|$39

F1 - USE WITH HOSE P/N 418-62-23950.

-1шт.

|$41

-1шт.

|$42

F2 - USE WITH HOSE P/N 418-62-A1620. F1 ITEMS ARE NO LONGER REQUIRED.

-1шт.

|$43

-1шт.
