Запчасти Komatsu WA250-3 ТРАНСМИССИЯ (2 И 4 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-13-10001

TORQFLOW ASS'Y

SN: 65040-UP

1шт.

|1

714-13-10000

TORQFLOW ASS'Y

SN: 65001-65039

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-70A0.

-1шт.

|1

714-13-12030

CLUTCH ASS'Y,2ND AND 4TH

SN: 65001-UP

1шт.

|1

714-13-12130

SHAFT ASS'Y

SN: 65001-UP

1шт.

1

0

SHAFT

SN: 65001-UP

1шт.

2

419-15-12750

ORIFICE

SN: 65001-UP

1шт.

3

0

HOUSING ASS'Y

SN: 65001-UP

1шт.

4

714-13-12660

PISTON,2ND AND 4TH

SN: 65001-UP

2шт.

5

714-12-19711

DISC

SN: (77652)-UP

9шт.

|5

0

DISC

SN: 65001-(77651)

9шт.

6

714-16-19730

PLATE,SEPARATE

SN: 65001-UP

11шт.

7

56D-15-12710

SPRING,WAVE

SN: 66062-UP

9шт.

|7

419-15-12133

SPRING,WAVE

SN: 65001-66061

9шт.

8

714-12-12610

PLATE,END

SN: 65001-UP

2шт.

9

419-15-12140

RING,SNAP

SN: 65001-UP

2шт.

10

714-16-19220

RING,SEAL

SN: 65001-UP

2шт.

11

714-16-19210

RING,SEAL

SN: 65001-UP

2шт.

12

714-08-19570

WASHER,THRUST

SN: 65001-UP

3шт.

13

714-11-19510

WASHER,THRUST

SN: 65001-UP

1шт.

14

419-15-12270

BEARING,NEEDLE

SN: 65001-UP

1шт.

15

419-15-12660

BEARING,NEEDLE

SN: 65001-UP

1шт.

16

419-15-13151

BEARING,NEEDLE

SN: (77760)-UP

1шт.

|16

0

BEARING,NEEDLE

SN: 65001-(77759)

1шт.

17

714-13-12460

GEAR¤ 43 TEETH,2ND

SN: 65001-UP

1шт.

18

714-13-12450

GEAR¤ 22 TEETH,4TH

SN: 65001-UP

1шт.

19

714-13-12530

GEAR¤ 26 TEETH,OUTPUT

SN: 65001-UP

1шт.

20

714-12-12520

GEAR¤ 31 TEETH,3RD

SN: 65001-UP

1шт.

21

714-13-19310

BEARING

SN: 65001-UP

1шт.

22

714-13-19320

BEARING

SN: 65001-UP

1шт.

23

714-12-19520

RING,SNAP

SN: 65001-UP

1шт.

24

419-15-12122

RING,SEAL

SN: 65001-UP

3шт.
