Запчасти Komatsu WA250-3 МАРКИРОВКА (С КАБИНОЙ) (ЯПОН.)(№-) КАТАЛОГИ ЗЧ

|1

417-93-21110

PLATE KIT

SN: 65001-65040

1шт.

1

0

PLATE¤ CAUTION,KEEP OUT

SN: 65001-65040

2шт.

2

0

PLATE¤ CAUTION,SAFETY BAR

SN: 65001-65040

1шт.

3

0

PLATE¤ INSTRUCTION,FUEL

SN: 65001-65040

1шт.

4

0

PLATE¤ SAFETY,RADIATOR CAP

SN: 65001-65040

1шт.

5

0

PLATE¤ INSTRUCTION,ENGINE OIL

SN: 65001-65040

1шт.

6

0

PLATE¤ CAUTION,BRAKE OIL

SN: 65001-65040

1шт.

7

0

PLATE¤ SAFETY,HYDRAULIC TANK CAP

SN: 65001-65040

1шт.

8

0

PLATE¤ CAUTION,BATTERY CABLE

SN: 65001-65040

1шт.

|9

418-93-21311

PLATE KIT

SN: 65001-65040

1шт.

9

0

PLATE¤ OPERATING,STARTING SWITCH

SN: 65001-65040

1шт.

10

0

PLATE¤ CAUTION,TRAVEL

SN: 65001-65040

1шт.

11

0

PLATE¤ NAME,FUSE

SN: 65001-65040

1шт.

12

0

PLATE¤ NAME,FUSE

SN: 65001-65040

1шт.

13

0

PLATE¤ INSTRUCTION,STEERING HOSE

SN: 65001-65040

1шт.

14

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 65001-65040

1шт.

15

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 65001-65040

1шт.

16

0

PLATE¤ SAFETY,WORK EQUIPMENT LEVER LOCK

SN: 65001-65040

1шт.

17

0

PLATE¤ SAFETY,BRAKE PEDAL

SN: 65001-65040

1шт.

18

0

PLATE¤ OPERATING,WORK EQUIPMENT LEVER

SN: 65001-65040

1шт.

19

0

PLATE¤ OPERATING,LOCK LEVER

SN: 65001-65040

1шт.

20

0

PLATE¤ CAUTION,PARKING BRAKE

SN: 65001-65040

1шт.

21

418-93-21220

PLATE¤ MARK,WA250

SN: 65001-@

2шт.

22

417-93-21220

PLATE¤ MARK,AVANCE LOADER

SN: 65001-@

2шт.

23

09690-B0280

PLATE¤ MARK,KOMATSU

SN: 65001-@

2шт.

24

417-93-21141

PLATE¤ MARK,KOMATSU

SN: 65001-@

1шт.

25

417-93-21150

PLATE¤ STRIPE,L.H.

SN: 65001-@

1шт.

26

417-93-21160

PLATE¤ STRIPE,R.H.

SN: 65001-@

1шт.

27

418-93-21330

CHART¤ OIL

SN: 65001-@

1шт.

28

09602-01635

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 65001-@

1шт.

|28

04418-13060

SCREW

SN: 65001-@

4шт.

29

418-93-21320

PLATE¤ DATA

SN: 65001-@

1шт.

30

417-54-24550

PLATE¤ CAUTION,(WITH REAR FENDER) (OP)

SN: 65001-@

2шт.

31

09807-C0880

PLATE¤ SAFETY,KEEP OUT

SN: 65001-65040

2шт.

32

09960-01001

PLATE¤ MARK,HANDLING

SN: 65001-@

4шт.

33

09806-C0880

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 65001-65040

2шт.

34

09667-A0880

PLATE¤ SAFETY,FAN

SN: 65001-65040

2шт.

35

423-904-1810

PLATE

SN: 65001-@

1шт.

36

09620-01200

PLATE¤ NAME,ROPS

SN: 65001-@

1шт.

|36

205-00-72430

RIVET

SN: 65001-@

4шт.

37

416-93-21170

PLATE

SN: 65034-@

1шт.

38

416-93-21180

PLATE

SN: 65034-@

1шт.
