Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$3
714-13-10001
TORQFLOW ASS'Y
SN: (77880)-UP
1шт.
|$4
714-13-10000
TORQFLOW ASS'Y
SN: 53001-(77879)
1шт.
|$$4
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.
-1шт.
|$6
714-13-15030
CONTROL VALVE ASS'Y
SN: (77721)-UP
1шт.
|$7
0
CONTROL VALVE ASS'Y
SN: 53001-(77720)
1шт.
|$$7
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0A.
-1шт.
|$9
419-15-15201
VALVE ASS'Y,UPPER
SN: 53001-UP
1шт.
1
419-15-15711
BODY,UPPER
SN: 53001-UP
1шт.
2
419-15-15720
COVER
SN: 53001-UP
1шт.
3
419-15-15730
COVER
SN: 53001-UP
1шт.
4
419-15-15741
GASKET (K2)
SN: 53001-UP
1шт.
5
419-15-15751
GASKET (K2)
SN: 53001-UP
1шт.
6
419-15-15760
VALVE,PILOT
SN: 53001-UP
1шт.
7
419-15-15770
VALVE,MAIN
SN: 53001-UP
1шт.
8
419-15-15780
VALVE,PRIORITY
SN: 53001-UP
1шт.
9
419-15-15790
VALVE,ACCUMULATOR
SN: 53001-UP
1шт.
10
419-15-15810
VALVE,MODULATE
SN: 53001-UP
1шт.
11
419-15-15820
PISTON,LOAD
SN: 53001-UP
1шт.
12
419-15-15830
PISTON,LOAD
SN: 53001-UP
1шт.
13
419-15-15840
VALVE,QUICK RETURN
SN: 53001-UP
1шт.
14
419-15-15850
PLUG,VALVE
SN: 53001-UP
1шт.
15
419-15-15860
SLEEVE,MODULATE
SN: 53001-UP
1шт.
16
419-15-15870
SHAFT,ACCUMULATOR
SN: 53001-UP
1шт.
17
419-15-15910
SPRING,MAIN
SN: 53001-UP
1шт.
18
419-15-15920
SPRING,PRIORITY
SN: 53001-UP
1шт.
19
419-15-15940
SPRING,INNER MODULATE
SN: 53001-UP
1шт.
20
419-15-15930
SPRING,OUTER MODULATE
SN: 53001-UP
1шт.
21
419-15-15950
SPRING,OUTER ACCUMULATOR
SN: 53001-UP
1шт.
22
419-15-15960
SPRING,INNER ACCUMULATOR
SN: 53001-UP
1шт.
23
419-15-15970
SPRING,INNER ACCUMULATOR
SN: 53001-UP
1шт.
24
419-15-15880
ROD,ADJUST
SN: 53001-UP
1шт.
25
419-15-15890
PLUG,MODULATE
SN: 53001-UP
1шт.
26
419-15-15980
RETAINER,MODULATE
SN: 53001-UP
1шт.
28
419-15-15510
SPRING,CHECK
SN: 53001-UP
1шт.
29
419-15-15640
PLUG
SN: 53001-UP
1шт.
34
417-15-15842
ORIFICE,MAIN
SN: 53001-UP
1шт.
Выбрано товаров: 46
