Запчасти Komatsu WA250-3 ТРАНСМИССИЯ (4 МУФТА)(№-) СИЛОВАЯ ПЕРЕДАЧА

|$0

714-13-10000

TORQFLOW ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271.

-1шт.

|$2

714-13-12030

CLUTCH ASS'Y,2ND AND 4TH

SN: 50001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2225 AND 2226.

-1шт.

|$4

714-13-12130

SHAFT ASS'Y

SN: 50001-UP

1шт.

1

0

SHAFT

SN: 50001-UP

1шт.

2

0

HOUSING ASS'Y

SN: 50001-UP

1шт.

3

419-15-12750

ORIFICE,(D=1.0MM)

SN: 50001-UP

1шт.

4

714-13-12660

PISTON,4TH

SN: 50001-UP

1шт.

5

714-16-19220

RING,SEAL

SN: 50001-UP

1шт.

6

714-16-19210

RING,SEAL

SN: 50001-UP

1шт.

7

714-12-19710

DISC

SN: 50001-UP

3шт.

8

714-16-19730

PLATE,SEPARATE

SN: 50001-UP

4шт.

9

419-15-12133

SPRING,WAVE

SN: 50001-UP

3шт.

10

714-12-12610

PLATE,END

SN: 50001-UP

1шт.

11

419-15-12140

RING,SNAP

SN: 50001-UP

1шт.

12

714-13-12450

GEAR, 22 TEETH,4TH

SN: 50001-UP

1шт.

13

419-15-12660

BEARING,NEEDLE

SN: 50001-UP

1шт.

14

419-15-12270

BEARING,NEEDLE

SN: 50001-UP

1шт.

15

714-08-19570

WASHER,THRUST

SN: 50001-UP

1шт.

16

714-11-19510

WASHER,THRUST

SN: 50001-UP

1шт.

17

714-12-12520

GEAR, 31 TEETH,3RD

SN: 50001-UP

1шт.

18

714-13-19310

BEARING

SN: 50001-UP

1шт.

19

419-15-12122

RING,SEAL

SN: 50001-UP

3шт.
