Запчасти Komatsu WA250-3 ТРАНСМИССИЯ (3 МУФТА)(№-) СИЛОВАЯ ПЕРЕДАЧА

|$0

714-13-10000

TORQFLOW ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271.

-1шт.

|$2

714-13-12020

CLUTCH ASS'Y,1ST AND 3RD

SN: 50001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2223 AND 2224.

-1шт.

|$4

714-13-12120

SHAFT ASS'Y

SN: 50001-UP

1шт.

1

0

SHAFT

SN: 50001-UP

1шт.

2

0

HOUSING ASS'Y

SN: 50001-UP

1шт.

3

714-13-12660

PISTON,3RD

SN: 50001-UP

1шт.

4

714-16-19210

RING,SEAL

SN: 50001-UP

1шт.

5

714-16-19220

RING,SEAL

SN: 50001-UP

1шт.

6

714-12-19710

DISC

SN: 50001-UP

4шт.

7

714-16-19730

PLATE,SEPARATE

SN: 50001-UP

5шт.

8

419-15-12133

SPRING,WAVE

SN: 50001-UP

4шт.

9

714-12-12610

PLATE,END

SN: 50001-UP

1шт.

10

419-15-12140

RING,SNAP

SN: 50001-UP

1шт.

11

714-13-12440

GEAR, 40 TEETH,FORWARD

SN: 50001-UP

1шт.

12

419-15-12660

BEARING,NEEDLE

SN: 50001-UP

1шт.

13

714-08-19570

WASHER,THRUST

SN: 50001-UP

1шт.

14

714-08-19560

WASHER,THRUST

SN: 50001-UP

1шт.

15

714-12-12740

SPACER

SN: 50001-UP

1шт.

16

06040-06211

BEARING

SN: 50001-UP

1шт.

17

419-15-12122

RING,SEAL

SN: 50001-UP

3шт.
