Запчасти Komatsu WA250-1LC CRANKING МОТОР - DELCO №99 9 КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

|$0

1243 026 H92

MOTOR ASSEMBLY, CRANKING

1шт.

1

1283 444 H1

FRAME, COMMUTATOR END

1шт.

|$2

NSS

BOLT

4шт.

2

NSS

BUSHING, COMMUTATOR END FRAME

1шт.

3

1210 065 H1

ARMATURE

1шт.

4

1283 445 H1

COIL, FIELD

1шт.

5

NSS

STOP, PINION

1шт.

6

1268 824 H91

HOUSING, LEVER

1шт.

|$8

1245 107 H1

SCREW, LEVER HOUSING MOUNTING

4шт.

7

NSS

BUSHING, LEVER HOUSING

1шт.

8

1210 067 H1

DRIVE, MOTOR

1шт.

9

1267 948 H1

HOUSING, DRIVE

1шт.

|$12

1245 105 H1

SCREW, DRIVE HOUSING MOUNTING

3шт.

10

NSS

BUSHING, DRIVE HOUSING

1шт.

11

1283 447 H1

SWITCH, SOLENOID

1шт.

|$15

1283 448 H1

SCREW AND WASHER, SWITCH MOUNTING

3шт.

12

NSS

BRUSH

1шт.

|$17

1211 292 H1

SCREW, BRUSH LEAD MOUNTING

1шт.

13

NSS

SPRING, BRUSH

1шт.

14

1283 452 H1

PLATE ASSEMBLY, BRUSH

1шт.

15

1228 450 H1

PLUNGER

1шт.

16

1210 071 H1

BOOT

1шт.

17

1210 073 H1

SPRING, PLUNGER

1шт.

18

NSS

LEVER, SHIFT

1шт.

19

NSS

WASHER, SPACER DRIVE END

1шт.

20

NSS

WASHER, BRAKE

1шт.

21

NSS

WASHER, COMMUTATOR END THRUST

1шт.

22

1210 058 H1

CONDUCTOR

1шт.

23

120 217

WASHER, SHUNT TERMINAL LOCK

2шт.

24

120 217

WASHER, SHUNT LEAD TO SWITCH ATTACHING

1шт.

25

1211 267 H1

NUT, FIELD COIL CONNECTOR TO SWITCH

1шт.

26

115 999

NUT, SHUNT LEAD TO SWITCH

1шт.

27

115 999

NUT, SHUNT TERMINAL

2шт.

28

NSS

NUT, PLUNGER ROD GUIDE ADJUSTING

1шт.

29

NSS

WICK, OIL RESERVOIR

3шт.

30

213 262 R1

RING, SHIFT LEVER SHAFT RETAINING

1шт.

31

1211 152 H1

SHAFT, SHIFT LEVER

1шт.

32

1211 292 H1

SCREW, FIELD COIL LEAD TO BRUSH HOLDER

3шт.

33

NSS

SEAL, OIL - LEVER HOUSING

1шт.

34

NSS

RING, PINION STOP RETAINER

1шт.

35

1210 074 H1

RETAINER, PLUNGER SPRING (13/32

1шт.

36

1210 072 H1

RETAINER, PLUNGER SPRING (1-13/16

1шт.

37

1283 448 H1

SCREW, CONNECTOR TO FIELD TERMINAL

1шт.

38

NSS

WASHER, SHUNT TERMINAL INSULATOR

1шт.

39

120 385

WASHER, FIELD TERMINAL

1шт.

40

NSS

WASHER, SHUNT TERMINAL

1шт.

41

1210 066 H1

PLUG, LEVER HOUSING INSPECTION

1шт.

42

1210 070 H1

WASHER, PLUNGER SPRING RETAINER

1шт.

43

1210 063 H1

BUSHING, SHUNT TERMINAL

1шт.

44

1268 221 H1

POLE SHOE

1шт.

|$50

1245 108 H1

SCREW, POLE SHOE

2шт.

45

1283 456 H1

CONNECTOR, FIELD TERMINAL TO SWITCH

1шт.

46

NSS

CUP, OIL RESERVOIR

3шт.

47

1228 454 H1

PIN, BRUSH PLATE LOCATOR SPRING

1шт.

48

347 360 R1

O-RING, DRIVE HOUSING AND LEVER HOUSING

1шт.

49

1211 151 H1

GASKET, LEVER HOUSING INSPECTION PLUG

1шт.

50

352 219 R1

O-RING, SHIFT LEVER SHAFT (3/8

1шт.

51

1210 057 H1

INSULATOR

1шт.

52

355 967 R1

O-RING, SHIFT LEVER SHAFT (1/2

1шт.

53

22 411 R1

O-RING, BETWEEN LEVER HOUSING AND FRAME

1шт.

54

1210 064 H1

INSULATOR, SHUNT TERMINAL

1шт.

55

1210 061 H1

INSULATOR, FIELD TERMINAL (INSIDE) FRAME

1шт.

56

1210 062 H1

INSULATOR, FIELD TERMINAL (OUTSIDE) FRAME

1шт.

57

NSS

LEAD, SHUNT TERMINAL IN FRAME TO SWITCH

-1шт.

|$64

RETURN TERMINAL

1шт.

58

NSS

O-RING, ON MOTOR FRAME

1шт.

59

NSS

O-RING, BETWEEN SWITCH AND LEVER HOUSING

1шт.

60

NSS

BODY, CRANKING MOTOR

1шт.

61

213 262 R1

RING, PLUNGER SPRING RETAINER

1шт.

62

120 394

WASHER, FLAT

1шт.

63

1245 106 H1

TERMINAL, SHUNT COIL

1шт.

64

1228 453 H1

INSULATOR, DRIVE END FIELD COIL (TRIANGLE)

1шт.

65

1283 448 H1

SCREW, FIELD COIL TO SWITCH

1шт.

|$73

1283 495 H1

KIT, BRUSH REPAIR

1шт.

|$74

1283 496 H1

KIT, BUSHING REPAIR

1шт.

|$75

1268 843 H1

KIT, SHIFT LEVER REPAIR

1шт.

|$86

-1шт.

|$77

F1 - INCLUDED IN KIT 1283 495 H1

-1шт.

|$87

-1шт.

|$79

F2 - INCLUDED IN KIT 1283 496 H1

-1шт.

|$88

-1шт.

|$81

F3 - INCLUDED IN KIT 1268 843 H1

-1шт.

|$89

-1шт.
