Запчасти Komatsu WA250-1LC МАРКИРОВКА (ФРАНЦИЯ) ТАБЛИЧКИS МАРКИРОВКАS

|$45

-1шт.

|$1

PERSONAL SAFETY PRODUCT GRAPHICS:

-1шт.

1

939 371 C3

CAUTION - LADDERS

2шт.

2

743 484 C3

CAUTION - ROLLOVER

1шт.

3

1132 721 C2

CAUTION - PRESSURIZED COOLING SYSTEM

1шт.

4

660 056 C3

CAUTION - HYDRAULIC RESERVOIR

1шт.

5

418-93-31120

CAUTION - BATTERY INSTALLATION

2шт.

6

417-93-A1210

CAUTION - BATTERY CHARGING

2шт.

7

417-93-A1270

CAUTION - TRANSMISSION OIL LEVEL

1шт.

8

419-93-31420

WARNING - USE ONLY ENGINE OIL

1шт.

9

417-93-A1220

CAUTION - OPERATOR INSTRUCTIONS

1шт.

10

417-93-A1280

WARNING - OPERATOR MANUAL

1шт.

11

417-93-A1240

DANGER - FRAME LOCKING BAR

1шт.

12

417-93-A1250

CAUTION - ENGINE FAN

2шт.

13

423-93-11520

DANGER - NO CLEARANCE - ARTICULATION

2шт.

14

1170 725 C2

EMERGENCY EXIT (ON WINDOW SILL)

1шт.

|$46

-1шт.

|$17

INSTRUCTIONAL PRODUCT GRAPHICS:

-1шт.

15

418-93-A1170

LUBE CHART

1шт.

16

1124 686 C2

DIESEL FUEL

1шт.

17

09685-00004

CONTROL LEVER LOCK

1шт.

18

09683-51070

STARTER SWITCH

1шт.

19

421-93-11132

BUCKET POSTION

1шт.

20

1120 094 C2

LIFT AND TIE DOWN LOCATION

4шт.

21

418-93-A1210

ELECTRONIC MONITOR DECAL (LOCATED ON WINDOW)

1шт.

22

417-93-A1190

ETHER START

1шт.

23

417-93-A1180

TRANSMISSION OIL TEMP

1шт.

24

418-93-A1190

FUSE IDENTIFICATION

1шт.

25

418-93-A1180

FUSE ACCESSORIES IDENTIFICATION

1шт.

26

1132 014 C2

ENGINE OIL DRAIN

1шт.

27

938 945 C2

RADIATOR DRAIN

1шт.

|$47

-1шт.

|$32

IDENTIFICATION PRODUCT GRAPHICS:

-1шт.

28

09690-C0315

1шт.

29

418-93-11351

2шт.

30

09690-C0224

2шт.

31

418-93-A1150

DECAL - LEFT HAND

1шт.

32

418-93-A1160

DECAL - RIGHT HAND

1шт.

|$48

-1шт.

|$39

MISCELLANEOUS PRODUCT GRAPHICS:

-1шт.

33

425-93-A1141

I.D. PLATE

1шт.

34

04418-13060

SCREW

4шт.

35

418-93-A1140

TAPE STRIPE

2шт.

|$49

-1шт.
