Запчасти Komatsu WA250-1LC КАБИНА ROPS ЗАДН. ОКНА - заводской номер A8 И UP РАМА

|$0

CAB ASSEMBLY, ROPS (SEE PG 05-080)

-29шт.

1

419-54-15511

GLASS, REAR WINDOW

1шт.

2

417-927-AC90

STRIP, WEATHER

1шт.

|$3

417-927-AN20

COVER ASSEMBLY, WIPER REAR

1шт.

3

NSS

COVER, REAR WIPER

1шт.

4

417-927-AE80

SEAL, REAR WIPER COVER

1шт.

5

01010-50620

BOLT, MOUNT WIPER COVER

4шт.

6

01643-30623

WASHER, FLAT

4шт.

7

01602-20619

WASHER, LOCK

4шт.

8

MOTOR, REAR WINDOW WIPER (SEE PG 05-096)

-29шт.

9

417-927-AG10

ARM, REAR WINDOW WIPER

1шт.

10

417-927-AG00

BLADE, REAR WINDOW WIPER

1шт.

N/I

417-927-AM70

PLUG, CAP

3шт.

N/I

417-927-AM60

PLUG, DOME

1шт.

|$16

-1шт.

|$15

F1-USED ON MACHINES NOT EQUIPPED WITH REAR WINDOW WIPER.

-1шт.

|$17

-1шт.
