Запчасти Komatsu WA200PZ-6 КОВШ (.9CBM) (С TEETH) (ТИП C) T РАБОЧЕЕ ОБОРУДОВАНИЕ

1

417-73-H2110

BUCKET ASSEMBLY

SN: H00051-UP

1шт.

2

417-72-H2210

EDGE, (WELDED)

SN: H00051-UP

1шт.

3

421-70-H2431

PLATE, (LIMITED SUPPLY)

SN: H00051-UP

1шт.

4

418-71-H2C50

WEAR PLATE

SN: H00051-UP

2шт.

5

417-72-H2430

PLATE, (WELDED)

SN: H00051-UP

2шт.

6

417-73-H2420

TRAY REINFORCEMENT, (WELDED)

SN: H00051-UP

1шт.

7

417-73-H2400

SKID, (WELDED)

SN: H00051-UP

2шт.

8

417-73-H2A00

EDGE, (WELDED)

SN: H00051-UP

1шт.

9

417-73-H2960

SIDE WALL, (WELDED)

SN: H00051-UP

1шт.

10

417-73-H2A00

EDGE, (WELDED)

SN: H00051-UP

1шт.

11

417-73-H2950

SIDE WALL, (WELDED)

SN: H00051-UP

1шт.

12

416-71-H2580

BOLT

SN: H00051-UP

4шт.

13

01643-32260

WASHER

SN: H00051-UP

4шт.

14

421-70-H2A20

NUT

SN: H00051-UP

4шт.

15

04418-03080

PIN

SN: H00051-UP

4шт.

16

42R-70-12B80

TOOTH ADAPTER, (WELDED)

SN: H00051-UP

1шт.

17

42R-70-12B80

TOOTH ADAPTER, (WELDED)

SN: H00051-UP

6шт.

18

42R-70-12B80

TOOTH ADAPTER, (WELDED)

SN: H00051-UP

1шт.

19

42R-70-12B70

TOOTH

SN: H00051-UP

8шт.

20

42R-70-12B90

TOOTH LOCK

SN: H00051-UP

8шт.
