Запчасти Komatsu WA200PZ-6 ТАБЛИЧКИ, EXTERIOR (№799-) ТАБЛИЧКИ, АНГЛ.

1

09806-C0883

Plate, Danger, Keep Away from Machine

SN: 70959-UP

2шт.

2

09807-C0883

Plate, Danger, Keep Out under Work Equipment

SN: 70959-UP

2шт.

3

09808-A1201

Plate, Warning, Battery Cables

SN: 70959-UP

2шт.

4

09161-C0641

Plate, Warning, Articulation Lock

SN: 70959-UP

1шт.

5

09162-C0641

Plate, Danger, Keep Off

SN: 70959-UP

2шт.

6

09653-A0641

Plate, Warning, High Temperature

SN: 70959-UP

2шт.

7

09667-A0880

Plate, Caution, Rotating Object

SN: 70959-UP

2шт.

8

417-93-42230

Decal, Stripe

SN: 70959-UP

2шт.

9

417-U77-4710

Decal, Machine Model,L.H.

SN: 70959-UP

1шт.

10

417-U77-4720

Decal, Machine Model,R.H.

SN: 70959-UP

1шт.

11

417-93-41720

Oil Chart

SN: 70959-UP

1шт.

12

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 70959-UP

4шт.

|$12

417-93-32260

Plate

SN: 70959-UP

1шт.

13

Plate, Rear Axle

SN: 70959-UP

1шт.

14

Plate, Radiator Drain

SN: 70959-UP

1шт.

15

Plate, Cylinder

SN: 70959-UP

1шт.

16

Plate, Steering Cylinder Head Pin R.H.

SN: 70959-UP

1шт.

17

Plate, Steering Cylinder Head Pin L.H.

SN: 70959-UP

1шт.

18

09669-0000E

Plate, Symbol, Fuel Filler,Inlet

SN: 70959-UP

1шт.

19

418-93-42410

Plate, Stripe, Low Clearance

SN: 70959-UP

4шт.

20

418-93-43341

Plate, Caution Cleaning Core, Rotation

SN: 70959-UP

1шт.

21

09690-C0800

Plate, Komatsu Logo

SN: 70959-UP

2шт.

22

20Y-00-41530

Plate, Symbol, Ecot3

SN: 70959-UP

1шт.

23

418-93-42240

Plate, Prefilter Cation, Pre Filter

SN: 70959-UP

1шт.

24

09963-A1640

Tag, Danger, Do Not Operate

SN: 70959-UP

1шт.

25

14X-98-35181

Plate, Reflector, Reflector

SN: 70959-UP

2шт.

26

09659-A057B

Plate, Warning, Explosion Hazard

SN: 70959-UP

4шт.
