Запчасти Komatsu WA200PT-5L ЦИЛИНДР СТРЕЛЫ(ВНУТР. ЧАСТИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

0

CYLINDER ASS'Y,L.H. (FINAL COATING)

SN: A89001-UP

1шт.

|$1

0

CYLINDER GROUP,L.H.

SN: A89001-UP

1шт.

|$2

0

CYLINDER ASS'Y,R.H. (FINAL COATING)

SN: A89001-UP

1шт.

|$3

0

CYLINDER GROUP,R.H.

SN: A89001-UP

1шт.

|$$5

====================

-1шт.

|$5

707-00-0E720

CYLINDER ASS'Y,L.H.

SN: A89001-UP

1шт.

|$6

707-00-0E730

CYLINDER ASS'Y,R.H.

SN: A89001-UP

1шт.

1

707-00-XZ730

CYLINDER ASS'Y,L.H.

SN: A89001-UP

1шт.

|$8

707-00-XZ740

CYLINDER ASS'Y,R.H.

SN: A89001-UP

1шт.

2

707-76-65580

BUSHING

SN: A89001-UP

1шт.

3

417-09-11120

SEAL,DUST

SN: A89001-UP

2шт.

4

707-29-12380

HEAD,CYLINDER

SN: A89001-UP

1шт.

5

707-52-10660

BUSHING

SN: A89001-UP

1шт.

6

707-51-65030

PACKING,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

7

144-63-92170

SEAL,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

8

07179-12079

RING,SNAP

SN: A89001-UP

1шт.

9

07000-12115

O-RING,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

10

07146-02116

RING,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

11

07000-12120

O-RING,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

12

707-59-65070

ROD,PISTON

SN: A89001-UP

1шт.

13

707-36-12130

PISTON

SN: A89001-UP

1шт.

14

707-44-12180

RING,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

15

07156-01215

RING,BOOM CYLINDER (KIT)

SN: A89001-UP

1шт.

16

707-67-45010

NUT,NYLON

SN: A89001-UP

1шт.

17

02896-11015

O-RING,BOOM CYLINDER (KIT)

SN: A89001-UP

2шт.

18

707-86-47620

TUBE,L.H.

SN: A89001-UP

1шт.

19

707-86-47630

TUBE,L.H.

SN: A89001-UP

1шт.

20

02896-11015

O-RING,BOOM CYLINDER (KIT)

SN: A89001-UP

2шт.

21

707-88-86550

PLATE

SN: A89001-UP

1шт.

22

07283-32244

CLIP

SN: A89001-UP

2шт.

23

07283-52232

SEAT

SN: A89001-UP

2шт.

24

01597-01009

NUT

SN: A89001-UP

4шт.

25

01643-31032

WASHER

SN: A89001-UP

4шт.

|$33

707-98-42150

SERVICE KIT,BOOM CYLINDER

SN: A89001-UP

2шт.
