Запчасти Komatsu WA200PT-5 ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ)(№-) AA ДВИГАТЕЛЬ

|$1

6738-71-1170

INJECTION PUMP ASSEMBLY

SN: 26316011-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4400-01A0 TO F4400-04A0.

-1шт.

|$3

DK101062-9340

PUMP ASSEMBLY

SN: 26316011-UP

1шт.

|$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4400-01A0 TO F4400-04A0.

-1шт.

1

DK131034-14

PLUG

SN: 26316011-UP

6шт.

2

DK131154-65

PLUNGER ASSEMBLY

SN: 26316011-UP

6шт.

3

DK131110-77

VALVE

SN: 26316011-UP

6шт.

4

DK131112-56

SPRING

SN: 26316011-UP

6шт.

5

DK131115-16

GASKET

SN: 26316011-UP

6шт.

6

DK131116-84

HOLDER

SN: 26316011-UP

6шт.

7

DK131117-31

STOPPER

SN: 26316011-UP

6шт.

8

DK131122-05

PLATE ASSEMBLY

SN: 26316011-UP

3шт.

9

DK139717-01

O-RING

SN: 26316011-UP

6шт.

10

DK131200-28

TAPPET ASSEMBLY

SN: 26316011-UP

6шт.

11

DK131203-08

PIN

SN: 26316011-UP

1шт.

12

DK131204-10

ROLLER

SN: 26316011-UP

1шт.

13

DK131205-05

BUSHING

SN: 26316011-UP

1шт.

14

DK131206-02

GUIDE

SN: 26316011-UP

1шт.

15

DK029311-05

SHIM, 0.2MM

SN: 26316011-UP

-26шт.

|$20

DK029311-05

SHIM, 0.25MM

SN: 26316011-UP

-26шт.

|$21

DK029311-00

SHIM, 0.30MM

SN: 26316011-UP

-26шт.

|$22

DK029311-06

SHIM, 0.35MM

SN: 26316011-UP

-26шт.

|$23

DK029311-00

SHIM, 0.40MM

SN: 26316011-UP

-26шт.

|$24

DK029311-06

SHIM, 0.45MM

SN: 26316011-UP

-26шт.

|$25

DK029311-00

SHIM, 0.50MM

SN: 26316011-UP

-26шт.

|$26

DK029311-02

SHIM, 0.55MM

SN: 26316011-UP

-26шт.

|$27

DK029311-00

SHIM, 0.6MM

SN: 26316011-UP

-26шт.

|$28

DK029311-02

SHIM, 0.65MM

SN: 26316011-UP

-26шт.

|$29

DK029311-00

SHIM, 0.7MM

SN: 26316011-UP

-26шт.

|$30

DK029311-02

SHIM, 0.75MM

SN: 26316011-UP

-26шт.

|$31

DK029311-00

SHIM, 0.8MM

SN: 26316011-UP

-26шт.

|$32

DK029311-03

SHIM, 0.85MM

SN: 26316011-UP

-26шт.

|$33

DK029311-00

SHIM, 0.9MM

SN: 26316011-UP

-26шт.

|$34

DK029311-03

SHIM, 0.95MM

SN: 26316011-UP

-26шт.

|$35

DK029311-00

SHIM, 1.0MM

SN: 26316011-UP

-26шт.

|$36

DK029311-03

SHIM, 1.05MM

SN: 26316011-UP

-26шт.

|$37

DK029311-01

SHIM, 1.1MM

SN: 26316011-UP

-26шт.

|$38

DK029311-03

SHIM, 1.15MM

SN: 26316011-UP

-26шт.

|$39

DK029311-01

SHIM, 1.2MM

SN: 26316011-UP

-26шт.

|$40

DK029311-03

SHIM, 1.25MM

SN: 26316011-UP

-26шт.

|$41

DK029311-01

SHIM, 1.3MM

SN: 26316011-UP

-26шт.

|$42

DK029311-06

SHIM, 1.35MM

SN: 26316011-UP

-26шт.

|$43

DK029311-01

SHIM, 1.4MM

SN: 26316011-UP

-26шт.

|$44

DK029311-06

SHIM, 1.45MM

SN: 26316011-UP

-26шт.

|$45

DK029311-04

SHIM, 1.5MM

SN: 26316011-UP

-26шт.

|$46

DK029311-07

SHIM, 1.55MM

SN: 26316011-UP

-26шт.

|$47

DK029311-05

SHIM, 1.6MM

SN: 26316011-UP

-26шт.

16

DK131215-25

SPRING

SN: 26316011-UP

6шт.

17

DK131216-01

SEAT

SN: 26316011-UP

6шт.

18

DK131217-02

SEAT

SN: 26316011-UP

6шт.

19

DK131256-09

RACK

SN: 26316011-UP

1шт.

20

DK131226-03

SCREW

SN: 26316011-UP

1шт.

21

DK131240-01

PINION

SN: 26316011-UP

6шт.

22

DK131241-01

SLEEVE

SN: 26316011-UP

6шт.

23

DK131242-01

SCREW

SN: 26316011-UP

6шт.
