Запчасти Komatsu WA200-5 НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$13

PARTS MARKED B6¤ CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B6.

-1шт.

|$1

PARTS MARKED B7¤ CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B7.

-1шт.

|1

417-18-31101

PUMP

SN: B10001-UP

1шт.

|1

0

GEAR PUMP

SN: B10001-UP

1шт.

1

UC1020777952

FLANGE (B6)

SN: B10001-UP

1шт.

2

UC1704491361

METAL (B6)

SN: B10001-UP

1шт.

3

UC1720131603

DRIVE SHAFT (B7)

SN: B10001-UP

1шт.

4

UC4020062587

GEAR (B6)

SN: B10001-UP

1шт.

5

UC1720256499

KEY (B7)

SN: B10001-UP

1шт.

6

UC1701569306

RING

SN: B10001-UP

1шт.

7

UC1090830917

BOLT

SN: B10001-UP

4шт.

8

UC1300449001

O-RING

SN: B10001-UP

1шт.

9

UC1300313003

O-RING

SN: B10001-UP

1шт.
