Запчасти Komatsu WA200-5 НАСОС (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

PARTS MARKED B4¤ CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B4.

-1шт.

|$1

PARTS MARKED B5¤ CANNNOT BE SUPPLIED AS AN INDIVIDUAL PART.IT IS SUPPLIED AS A S ET OF OTHER PARTS MARKED B5.

-1шт.

|1

417-18-31101

PUMP

SN: B10001-UP

1шт.

|1

UC4100656147

COVER

SN: B10001-UP

1шт.

1

0

RELIEF VALVE

SN: B10001-UP

2шт.

2

0

VALVE

SN: B10001-UP

1шт.

3

0

CUT-OFF VALVE

SN: B10001-UP

1шт.

4

UC1100656159

COVER (B4)

SN: B10001-UP

1шт.

5

UC1704491361

METAL (B4)

SN: B10001-UP

1шт.

6

UC1301638009

BOLT

SN: B10001-UP

4шт.

7

UC1303046816

O-RING

SN: B10001-UP

1шт.

8

UC1701539213

PLUG (B4)

SN: B10001-UP

1шт.

9

UC1300038005

O-RING

SN: B10001-UP

1шт.

10

0

PLUG

SN: B10001-UP

2шт.

11

UC1701516926

PLUG

SN: B10001-UP

1шт.

12

UC1704405379

BUSHING (B5)

SN: B10001-UP

1шт.

13

UC1704357904

METAL (B5)

SN: B10001-UP

1шт.

14

UC1701538807

PLUG (B4)

SN: B10001-UP

2шт.
