Запчасти Komatsu WA200-3-SN ОБОГРЕВАТЕЛЬ. И АНТИОБЛЕДЕНИТЕЛЬ (ОТОПИТЕЛЬ /) OPERATIORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|1

425-07-23110

.HEATER UNIT

SN: 63001-UP

1шт.

|$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0710-05A1 AND K0710-06A1.

-1шт.

|1

ND113140-0120

..UNIT ASS'Y,HEATER

SN: 63001-UP

1шт.

1

ND245420-4200

...CASE ASS'Y

SN: 63001-UP

1шт.

2

ND116730-0520

...DAMPER ASS'Y

SN: 63001-UP

1шт.

3

ND116730-0530

...DAMPER ASS'Y

SN: 63001-UP

1шт.

4

ND245420-0210

...CASE ASS'Y

SN: 63001-UP

1шт.

5

ND116452-0561

...CASE,HEATER

SN: 63001-UP

1шт.

6

ND949001-1730

...SCREW,TAPPING

SN: 63001-UP

11шт.

7

ND116410-9680

...UNIT ASS'Y,RADIATOR

SN: 63001-UP

1шт.

8

ND116427-5540

...PIPE

SN: 63001-UP

1шт.

9

ND7052-200600

...HOSE,WATER

SN: 63001-UP

3шт.

10

ND949351-0720

...CLAMP,HOSE

SN: 63001-UP

6шт.

11

ND113600-9260

...VALVE ASS'Y,WATER

SN: 63001-UP

1шт.

12

ND116427-2320

...PIPE

SN: 63001-UP

1шт.

13

ND017231-1400

...CLAMP

SN: 63001-UP

1шт.

14

ND246440-5200

...WIRING HARNESS,WIRE

SN: 63001-UP

1шт.

15

ND017732-3050

...LEVER,CONTROL

SN: 63001-UP

1шт.

16

ND91370-03081

...SCREW,WASHER

SN: 63001-UP

3шт.

17

ND017732-3041

...LEVER,CONTROL

SN: 63001-UP

1шт.

18

ND017732-3060

...LEVER,CONTROL

SN: 63001-UP

1шт.

19

ND146625-5040

...BUSHING

SN: 63001-UP

2шт.

20

ND116662-3780

...SHAFT

SN: 63001-UP

1шт.

21

ND246690-2930

...CLAMP

SN: 63001-UP

2шт.

22

ND116662-0590

...SHAFT

SN: 63001-UP

1шт.

23

ND063700-6580

...SERVO MOTOR ASS'Y

SN: 63001-UP

1шт.

24

ND146625-2630

...BUSHING

SN: 63001-UP

1шт.

25

ND90930-06141

...SCREW,TAPPING

SN: 63001-UP

9шт.

26

ND146668-6710

...PACKING

SN: 63001-UP

1шт.

27

ND246690-6740

...CLAMP

SN: 63001-UP

3шт.

28

ND017773-0140

...CLIP

SN: 63001-UP

1шт.

29

ND017773-0180

...CLIP

SN: 63001-UP

1шт.

30

ND949008-0780

...SCREW,TAPPING

SN: 63001-UP

2шт.

31

ND017660-3490

...BRACKET

SN: 63001-UP

2шт.

32

ND90930-05121

...SCREW,TAPPING

SN: 63001-UP

3шт.

33

ND146984-4080

...GROMMET

SN: 63001-UP

1шт.

34

ND145840-1210

...GUIDE,AIR

SN: 63001-UP

1шт.

35

ND146625-7620

...BUSHING

SN: 63001-UP

1шт.

22

ND116662-0590

...SHAFT

SN: 63001-UP

1шт.

23

ND063700-6580

...SERVO MOTOR ASS'Y

SN: 63001-UP

1шт.
