Артикул
Название
Примечание
Количество
|1
361-17-21302
PUMP ASS'Y,(A4VG28DA-930-0)
SN: 11896-UP
1шт.
|1
361-17-21301
PUMP ASS'Y,(A4VG28DA-987-2)
SN: 11270-11895
1шт.
|1
361-17-21200
PUMP ASS'Y,(A4VG28DA-987-1)
SN: 10842-11269
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1610-01A0B TO Y1610-07A0B .
-1шт.
|$$5
THE UCHIDA YUATSU PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
UCBA041S9137-0
PUMP ASS'Y
SN: 11896-UP
1шт.
|1
UCB1043R9639-0
PUMP ASS'Y,PISTON
SN: 10842-11895
1шт.
|$$8
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1610-02A0A TO Y1610-06A0.
-1шт.
|1
UC4100571211
COVER ASS'Y
SN: 11896-UP
1шт.
|1
0
COVER ASS'Y
SN: 10842-11895
1шт.
1
UC1100559773
COVER,PISTON
SN: 11896-UP
1шт.
|1
0
COVER
SN: 10842-11895
1шт.
2
02891-02081
O-RING
SN: 10001-UP
1шт.
3
UC1300034003
O-RING
SN: 10001-UP
1шт.
4
02890-01088
O-RING
SN: 10001-UP
1шт.
4A
UC1701570838
RING
SN: 10001-UP
1шт.
5
01252-31260
BOLT
SN: 10001-UP
4шт.
6
UC1100354275
COUPLING
SN: 10001-UP
1шт.
7
UC1701532459
BEARING
SN: 10001-UP
1шт.
8
UC1701539213
PLUG
SN: 11896-UP
1шт.
|8
0
PLUG
SN: 10001-11895
1шт.
10
UC1301169009
O-RING
SN: 10842-UP
1шт.
11
UC1701533389
PLUG
SN: 10001-UP
1шт.
|12
UC4100368143
RELIEF VALVE ASS'Y,HIGH PRESSURE
SN: 10001-UP
2шт.
12
0
VALVE ASS'Y
SN: 10001-11895
1шт.
13
UC1300146005
O-RING
SN: 10001-UP
2шт.
14
UC1300166009
O-RING
SN: 10001-UP
1шт.
15
UC1609041827
NUT
SN: 10001-UP
1шт.
16
UC1100310514
NUT,CAP
SN: 10001-UP
1шт.
17
UC1800042449
O-RING
SN: 10001-UP
2шт.
|18
UC4704336674
RELIEF VALVE ASS'Y,LOW PRESSURE
SN: 10001-UP
1шт.
18
UC1704328209
GUIDE
SN: 10001-UP
1шт.
19
UC1704328199
PLUNGER
SN: 10001-UP
1шт.
20
UC1704244615
SPRING
SN: 10001-UP
1шт.
21
UC1701537996
SHIM¤ 0.5MM
SN: 10001-UP
1шт.
|21
UC1701570782
SHIM¤ 1.0MM
SN: 10001-UP
1шт.
|21
UC1701578667
SHIM¤ 0.3MM
SN: 10001-UP
1шт.
22
UC1704328189
PLUG
SN: 10001-UP
1шт.
|24
UC4100368152
DA CURTRIDGE ASS'Y
SN: 10001-UP
1шт.
24
UC4100372775
DA CURTRIDGE ASS'Y
SN: 10001-11895
1шт.
26
UC1300170008
O-RING
SN: 10001-UP
1шт.
27
UC1609041836
NUT
SN: 10001-UP
1шт.
28
UC1100310505
NUT,CAP
SN: 10001-UP
1шт.
29
02890-01009
O-RING
SN: 10001-UP
2шт.
Выбрано товаров: 47
