Запчасти Komatsu WA180PT-3L ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6735-11-1140

HEAD, CYLINDER

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

6736-11-1150

PLUG, EXPANSION

5шт.

3

6732-11-1930

PLUG, PIPE (1/8 NPT)

2шт.

4

6732-11-1910

PLUG, PIPE (1/2 NPT)

5шт.

|$5

6736-41-4110

VALVE, INTAKE

6шт.

5

6732-41-4520

COLLET, VALVE

12шт.

9

NSS

VALVE, INTAKE

6шт.

|$8

6736-41-4210

VALVE, EXHAUST

6шт.

5

6732-41-4520

COLLET, VALVE

12шт.

10

NSS

VALVE, EXHAUST

6шт.

6

6732-41-4410

SPRING, VALVE

12шт.

7

6732-41-4510

RETAINER, VALVE SPRING

12шт.

8

6732-41-4530

SEAL, VALVE STEM

6шт.

8

6732-41-4540

SEAL, VALVE STEM

6шт.

11

6732-11-1920

PLUG, PIPE (3/4 NPT)

1шт.

12

6732-11-1610

BOLT (M12x1.75x70)

6шт.

13

6732-11-1620

BOLT (M12x1.75x120)

14шт.

19

6735-11-1811

GASKET, CYLINDER HEAD (STD)

1шт.

|$19

6735-19-1820

GASKET, CYLINDER HEAD (.15 MM O/S)

1шт.

|$20

6735-11-1830

GASKET, CYLINDER HEAD (.50 MM O/S)

1шт.

|$31

-1шт.

|$22

SERVICE PARTS

-1шт.

14

6736-19-1440

INSERT, VALVE (EXHAUST)

-2шт.

15

6736-19-1430

INSERT, VALVE (INTAKE)

-2шт.

16

6736-19-1310

GUIDE, VALVE STEM - LONG INTAKE (THICK WALL)

-2шт.

17

6736-19-1410

GUIDE, VALVE STEM - LONG EXHAUST (THICK WALL)

-2шт.

18

6736-18-1310

GUIDE, VALVE STEM - INTAKE/EXHAUST (THIN WALL)

-2шт.

|$32

-1шт.

|$29

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$30

ASSEMBLIES CATALOG.

-1шт.
