Запчасти Komatsu WA180PT-3L FIG NO. U-A МАРКИРОВКА (С КАБИНОЙ) (АНГЛ.) МАРКИРОВКА

|$0

417-93-21310

PLATE KIT

1шт.

1

NSS

PLATE, SAFETY, KEEP OUT

2шт.

2

NSS

PLATE, SAFETY, SAFETY BAR

1шт.

3

NSS

PLATE, INSTRUCTION, FUEL

1шт.

4

NSS

PLATE, SAFETY, RADIATOR CAP

1шт.

5

NSS

PLATE, INSTRUCTION, ENGINE OIL

1шт.

6

NSS

PLATE, SAFETY, BRAKE OIL

1шт.

7

NSS

PLATE, SAFETY, HYDRAULIC TANK CAP

1шт.

8

NSS

PLATE, SAFETY, BATTERY CABLE

1шт.

|$9

417-93-21360

PLATE KIT

1шт.

9

NSS

PLATE, OPERATING, STARTING SWITCH

1шт.

10

NSS

PLATE, NAME, FUSE

1шт.

11

NSS

PLATE, NAME, FUSE

1шт.

12

NSS

PLATE, SAFETY, BEFORE OPERATING

1шт.

13

NSS

PLATE, SAFETY, BRAKE PEDAL

1шт.

14

NSS

PLATE, SAFETY, WORK EQUIPMENT LEVER LOCK

1шт.

15

NSS

PLATE, SAFETY, INSPECTION

1шт.

16

NSS

PLATE, OPERATING, WORK EQUIPMENT LEVER

1шт.

17

NSS

PLATE, OPERATING, LOCK LEVER

1шт.

18

NSS

PLATE, CAUTION, PARKING BRAKE

1шт.

19

417-93-21330

PLATE, MARK, WA180

2шт.

20

417-93-21220

PLATE, MARK, AVANCE LOADER

2шт.

21

417-93-21010

PLATE, MARK, KOMATSU

2шт.

22

417-93-21141

PLATE, MARK, KOMATSU

1шт.

23

417-93-21150

PLATE, STRIPE, L.H

1шт.

24

417-93-21160

PLATE, STRIPE, R.H

1шт.

25

417-93-21370

CHART, OIL

1шт.

26

09602-10010

PLATE, NAME (LIMITED SUPPLY)

1шт.

|$28

04418-13060

SCREW

4шт.

27

09805-03000

PLATE, CAUTION (WITH FULL FENDER)

2шт.

28

417-56-21630

PLATE, OPERATING, DOOR LOCK

2шт.

29

09806-C0880

PLATE, CAUTION, KEEP A SAFE DISTANCE

2шт.

30

09667-A0880

PLATE, SAFETY, FAN

2шт.

31

09807-C0880

PLATE, CAUTION, KEEP OUT

2шт.

32

09960-01001

PLATE, MARK HANDLING, LIFT HERE

4шт.

33

417-46-25120

PLATE (NOT ILLUSTRATED)

2шт.

34

417-93-21340

PLATE (NOT ILLUSTRATED)

1шт.

35

1170 724 C2

PLATE, EMERGENCY EXIT (NOT ILLUSTRATED)

1шт.

36

417-U77-A650

DECAL, ROLLBACK TO LOCK (NOT ILLUSTRATED)

1шт.
