Запчасти Komatsu WA180PT-3L ШАТУН & ПОРШЕНЬ ДВИГАТЕЛЬ

1

6732-31-3100

ROD, ENGINE CONNECTING

6шт.

2

6732-31-3310

BOLT, CONNECTING ROD CAP (MJ11x1.25x59)

2шт.

8

6732-31-3130

BUSHING

1шт.

3

6732-31-3410

BEARING, CONNECTING ROD (STD)

2шт.

|$4

6736-39-3400

BEARING, CONNECTING ROD (0.25mm OVERSIZE)

-2шт.

|$5

6736-38-3400

BEARING, CONNECTING ROD (0.50mm OVERSIZE)

-2шт.

|$6

6736-37-3400

BEARING, CONNECTING ROD (0.75mm OVERSIZE)

-2шт.

|$7

6736-36-3400

BEARING, CONNECTING ROD (1.00mm OVERSIZE)

-2шт.

|$8

6735-31-2140

KIT, ENGINE PISTON (STD, COMP RATIO 17.3)

6шт.

4

NSS

KIT, ENGINE PISTON

6шт.

5

6736-31-2510

RING, RETAINING

2шт.

6

6732-31-2300

SET, PISTON RING

1шт.

7

6736-31-2420

PIN, PISTON

6шт.

|$13

6735-39-2210

KIT, ENGINE PISTON (0.50mm OVERSIZE)

6шт.

4

NSS

KIT, ENGINE PISTON

6шт.

5

6736-31-2510

RING, RETAINING

2шт.

6

6732-39-2300

SET, PISTON RING

1шт.

|$17

6735-38-2210

KIT, ENGINE PISTON (1.00mm OVERSIZE)

6шт.

4

NSS

KIT, ENGINE PISTON

6шт.

5

6736-31-2510

RING, RETAINING

2шт.

6

6732-38-2300

SET, PISTON RING

1шт.

|$$22

-1шт.

|$22

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$23

ASSEMBLIES CATALOG.

-1шт.
