Запчасти Komatsu WA180PT-3 КЛАПАН УПРАВЛЕНИЯ ТРАНСМИССИЕЙ (/) (НИЖНИЙ КЛАПАН) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$5

714-11-10003

TRANSMISSION ASS'Y

SN: (68569)-UP

1шт.

|$6

714-11-10002

TRANSMISSION ASS'Y

SN: 50001-(68568)

1шт.

|$7

714-11-10043

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: (68573)-UP

1шт.

|$8

714-11-10042

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 50001-(68572)

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.

-1шт.

|$10

714-11-15031

VALVE ASS'Y

SN: (68611)-UP

1шт.

|$11

714-11-15030

CONTROL VALVE ASS'Y

SN: (67749)-(68610)

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-60A0 TO F4350-62A0.

-1шт.

|$13

714-11-16200

VALVE ASS'Y,LOWER

SN: (67749)-UP

1шт.

|$$11

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0A AND 62A0A.

-1шт.

1

419-15-16521

BODY,LOWER

SN: 50001-UP

1шт.

2

419-15-16530

COVER

SN: 50001-UP

1шт.

3

419-15-16541

GASKET (K2)

SN: 50001-UP

1шт.

4

419-15-16551

GASKET (K2)

SN: 50001-UP

1шт.

5

419-15-16560

VALVE,T/C REGULATOR SELECTOR

SN: 50001-UP

1шт.

6

714-11-15210

VALVE,FORWARD AND REVERSE SELECTOR

SN: 50001-UP

1шт.

7

714-11-15230

VALVE,H-L SELECTOR

SN: 50001-UP

1шт.

8

714-11-15220

VALVE,SPEED SELECTOR

SN: 50001-UP

1шт.

9

419-15-16610

SPRING,T/C REGULATOR SELECTOR

SN: 50001-UP

1шт.

10

419-15-16620

SPRING,RETURN

SN: 50001-UP

2шт.

11

419-15-16631

SPACER,SPRING

SN: 50001-UP

2шт.

12

02720-10104

PLUG

SN: 50001-UP

1шт.

13

419-15-16640

RETAINER,SPRING

SN: 50001-UP

1шт.

14

419-15-16650

SHIM, 1.0MM

SN: 50001-UP

5шт.

15

417-15-17191

SLEEVE

SN: 50001-UP

2шт.

16

417-15-17280

SPRING

SN: 50001-UP

2шт.

17

07042-80108

PLUG

SN: 50001-UP

1шт.

18

01010-81030

BOLT

SN: 50001-UP

2шт.

19

01010-81055

BOLT

SN: 50001-UP

7шт.

20

419-15-15640

PLUG

SN: 50001-UP

1шт.

21

415-15-15430

PLUG

SN: 50001-UP

1шт.
