Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$3
714-11-10003
TRANSMISSION ASS'Y
SN: 54001-UP
1шт.
|$4
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 54001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-66A0.
-1шт.
|$8
714-11-12141
SHAFT ASS'Y
SN: 54001-UP
1шт.
1
0
SHAFT
SN: 54001-UP
1шт.
2
0
HOUSING ASS'Y
SN: 54001-UP
1шт.
3
714-11-12650
PISTON,FORWARD
SN: 54001-UP
1шт.
4
714-11-12660
PISTON,2ND
SN: 54001-UP
1шт.
7
0
SPRING,WAVE
SN: (54001-(170423))
14шт.
8
714-08-12610
PLATE,END
SN: 54001-UP
2шт.
9
714-08-19510
RING,SNAP
SN: 54001-UP
2шт.
11
714-11-19240
RING,SEAL
SN: 54001-UP
1шт.
16
714-11-12430
GEAR, 47 TEETH,FORWARD
SN: 54001-UP
1шт.
17
714-11-12440
GEAR, 27-49 TEETH,2ND
SN: 54001-UP
1шт.
Выбрано товаров: 28
