Запчасти Komatsu WA180-3MC FIG. E-A ГЕНЕРАТОР - A ЭЛЕКТРИКА

|$0

1310 137 H91

ALTERNATOR ASSEMBLY

SN: A81001-UP-UP

1шт.

1

1307 324 H1

FRAME, SRE

SN: A81001-UP-UP

1шт.

2

1236 651 H1

BEARING, SRE

SN: A81001-UP-UP

1шт.

3

1307 325 H1

ROTOR

SN: A81001-UP-UP

1шт.

4

1310 140 H1

STATOR

SN: A81001-UP-UP

1шт.

5

1307 327 H1

FRAME, DE

SN: A81001-UP-UP

1шт.

6

1213 268 H1

BEARING, DE

SN: A81001-UP-UP

1шт.

7

1310 141 H1

RECTIFIER BRIDGE

SN: A81001-UP-UP

1шт.

8

1307 329 H1

DIODE TRIO

SN: A81001-UP-UP

1шт.

9

1218 115 H1

REGULATOR

SN: A81001-UP-UP

1шт.

10

1307 330 H1

TERMINAL PACKAGE - OUTPUT

SN: A81001-UP-UP

1шт.

11

1307 331 H1

TERMINAL PACKAGE - RELAY

SN: A81001-UP-UP

1шт.

12

1307 332 H1

CONNECTOR

SN: A81001-UP-UP

1шт.

13

1307 333 H1

CONNECTOR

SN: A81001-UP-UP

1шт.

14

1307 334 H1

CAPACITOR

SN: A81001-UP-UP

1шт.

|$15

1307 335 H1

BRUSH HOLDER

SN: A81001-UP-UP

1шт.

15

NSS

HOLDER, BRUSH

SN: A81001-UP-UP

1шт.

16

NSS

SPRING, BRUSH

SN: A81001-UP-UP

2шт.

17

NSS

SPACER, BRUSH

SN: A81001-UP-UP

1шт.

18

NSS

SCREW, ATTACHING

SN: A81001-UP-UP

2шт.

19

1307 336 H1

BRUSH AND ARM

SN: A81001-UP-UP

1шт.

20

1307 337 H1

RETAINER

SN: A81001-UP-UP

1шт.

21

1218 242 H1

BUSHING

SN: A81001-UP-UP

1шт.

22

1307 338 H1

FAN

SN: A81001-UP-UP

1шт.

23

1218 126 H1

NUT

SN: A81001-UP-UP

1шт.

24

120 622

NUT

SN: A81001-UP-UP

5шт.

25

1213 273 H1

NUT

SN: A81001-UP-UP

1шт.

26

1268 365 H1

SCREW

SN: A81001-UP-UP

2шт.

27

1236 654 H1

SCREW

SN: A81001-UP-UP

1шт.

28

1268 365 H1

SCREW

SN: A81001-UP-UP

1шт.

29

1216 375 H1

SCREW

SN: A81001-UP-UP

2шт.

30

1307 339 H1

SCREW

SN: A81001-UP-UP

1шт.

31

1268 363 H1

SCREW

SN: A81001-UP-UP

3шт.

32

1307 340 H1

SCREW

SN: A81001-UP-UP

1шт.

33

1268 370 H1

WASHER

SN: A81001-UP-UP

1шт.

34

1307 341 H1

BOLT, THRU

SN: A81001-UP-UP

4шт.

35

1307 342 H1

CONNECTOR

SN: A81001-UP-UP

1шт.
