|$0
417-850-2200
LIFT ARM ASSEMBLY
SN: A80633-UP-UP
1шт.
1
NSS
ARM, HI-LIFT
SN: A80633-UP-UP
1шт.
2
416-70-11810
BUSHING
SN: A80633-UP-UP
2шт.
3
416-70-11860
BUSHING
SN: A80633-UP-UP
4шт.
4
416-09-11140
SEAL, DUST
SN: A80633-UP-UP
4шт.
5
416-09-11120
SEAL, DUST
SN: A80633-UP-UP
8шт.
|$6
417-70-21210
BELLCRANK ASSEMBLY
SN: A80633-UP-UP
1шт.
6
NSS
BELLCRANK
SN: A80633-UP-UP
1шт.
7
417-70-11860
BUSHING
SN: A80633-UP-UP
2шт.
8
417-09-11120
SEAL, DUST
SN: A80633-UP-UP
2шт.
9
07020-00000
FITTING, GREASE
SN: A80633-UP-UP
1шт.
|$11
417-850-0020
LINK ASSEMBLY
SN: A80633-UP-UP
1шт.
10
NSS
LINK
SN: A80633-UP-UP
1шт.
11
416-70-11810
BUSHING
SN: A80633-UP-UP
2шт.
12
416-09-11140
SEAL, DUST
SN: A80633-UP-UP
4шт.
13
07020-00000
FITTING, GREASE
SN: A80633-UP-UP
2шт.
14
416-70-11910
PIN
SN: A80001-UP-UP
2шт.
15
07020-00000
FITTING, GREASE
SN: A80001-UP-UP
2шт.
16
416-70-11460
SHIM - 0.020 IN. (0.50 MM)
SN: A80001-UP-UP
4шт.
|$19
416-70-11410
SHIM - 0.059 IN. (1.50 MM)
SN: A80001-UP-UP
2шт.
|$20
416-70-11420
SHIM - 0.118 IN. (3.00 MM)
SN: A80001-UP-UP
2шт.
17
01010-81220
BOLT
SN: A80001-UP-UP
2шт.
18
175-54-34170
WASHER
SN: A80001-UP-UP
2шт.
19
416-70-11921
PIN
SN: A80001-UP-UP
1шт.
20
416-70-11460
SHIM - 0.020 IN. (0.50 MM)
SN: A80001-UP-UP
4шт.
|$25
416-70-11420
SHIM - 0.118 IN. (3.00 MM)
SN: A80001-UP-UP
1шт.
|$26
416-70-11410
SHIM - 0.059 IN. (1.50 MM)
SN: A80001-UP-UP
2шт.
21
01010-81220
BOLT
SN: A80001-UP-UP
1шт.
22
175-54-34170
WASHER
SN: A80001-UP-UP
1шт.
23
416-70-11921
PIN
SN: A80001-UP-UP
2шт.
24
416-70-11460
SHIM - 0.020 IN. (0.50 MM)
SN: A80001-UP-UP
2шт.
|$31
416-70-11410
SHIM - 0.059 IN. (1.50 MM)
SN: A80001-UP-UP
2шт.
25
01010-81220
BOLT
SN: A80001-UP-UP
2шт.
26
175-54-34170
WASHER
SN: A80001-UP-UP
2шт.
27
SHIM - 0.059 IN. (1.50 MM)(SEE FIG. T4110-02A1)
SN: A80001-UP-UP
-1шт.
28
SHIM - 0.059 IN. (1.50 MM)(SEE FIG. T4110-02A1)
SN: A80001-UP-UP
-1шт.
29
SHIM - 0.059 IN. (1.50 MM)(SEE FIG. T4110-02A1)
SN: A80001-UP-UP
-1шт.
30
PIN (SEE FIG. T4110-02A1)
SN: A80001-UP-UP
-1шт.
