Запчасти Komatsu WA180-3L FIG. K7-A КОНДИЦ. ВОЗДУХА - ТРУБЫ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

AIR CONDITIONER KIT(SEE FIG. K0710-01A0)

SN: A80001-UP-UP

-1шт.

|$1

417-963-A520

HOSE KIT, DRYER

SN: A80001-UP-UP

1шт.

1

417-963-A530

HOSE, RETURN

SN: A80001-UP-UP

1шт.

2

417-963-A560

HOSE, PRESSURE

SN: A80001-UP-UP

1шт.

3

651 569 C1

CLAMP

SN: A80001-UP-UP

5шт.

4

425-963-A350

HOSE, DRAIN

SN: A80001-UP-UP

2шт.

N/I

425-963-AF10

HOSE, DRAIN

SN: A80001-UP-UP

1шт.

N/I

425-963-AA10

VALVE, DRAIN CHECK

SN: A80001-UP-UP

1шт.

N/I

425-963-AA70

UNION, HOSE BARB

SN: A80001-UP-UP

1шт.

5

417-963-A540

HOSE, CONDENSER

SN: A80001-UP-UP

1шт.

6

425-963-A460

WIRE, JUMPER

SN: A80001-UP-UP

1шт.

7

417-963-A550

HOSE, DRYER

SN: A80001-UP-UP

1шт.

8

A/C COMPRESSOR ASSEMBLY (SEE FIG. K0710-06A1)

SN: A80001-UP-UP

-1шт.

9

A/C CONDENSER ASSEMBLY (SEE FIG. K0710-06A3)

SN: A80001-UP-UP

-1шт.

10

BOX ASSEMBLY, A/C COIL (SEE FIG. K0710-04A0)

SN: A80001-UP-UP

-1шт.

|$15

416-963-A170

DRYER ASSEMBLY

SN: A80001-UP-UP

1шт.

11

416-963-A180

DRYER

SN: A80001-UP-UP

1шт.

12

416-963-A190

KIT, DRYER MOUNTING

SN: A80001-UP-UP

1шт.

|$18

1431 745 H2

BRACKET, DRYER

SN: A80001-UP-UP

1шт.

|$19

419-963-AA10

SWITCH, HIGH-PRESSURE

SN: A80001-UP-UP

1шт.

|$20

418-T42-A420

TIE STRAP

SN: A80001-UP-UP

2шт.

|$21

-1шт.

|$22

F1 - SEE PARTS AND SERVICE NEWS AA98123 PAGE 43 OF 71.

-1шт.

|$23

-1шт.
