Запчасти Komatsu WA180-3L FIG. K7-A КАБИНА - КОНДИЦ. ВОЗДУХА ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

417-963-A630

AIR CONDITIONER KIT

SN: A80001-UP-UP

1шт.

1

BOX ASSEMBLY, FILTER (SEE FIG. K0710-02A0)

SN: A80001-UP-UP

-1шт.

2

BOX ASSEMBLY, FAN (SEE FIG. K0710-03A0)

SN: A80001-UP-UP

-1шт.

|$3

COVER (SEE FIG. K0713-01A0)

SN: A80001-UP-UP

-1шт.

N/I

419-942-A510

A/C AND HEATER HARDWARE KIT

SN: A80001-A80338-UP

1шт.

3

A/C KIT (SEE FIG. K0710-04A0)

SN: A80001-UP-UP

-1шт.

N/I

423-942-A240

PROBE, TEMPERATURE

SN: A80001-UP-UP

1шт.

N/I

ELECTRICAL WIRING, A/C (SEE FIG. K0710-05A0)

SN: A80001-UP-UP

-1шт.

N/I

A/C PIPING (SEE FIG. K0710-06A0)

SN: A80001-UP-UP

-1шт.

N/I

A/C COMPRESSOR ASSEMBLY (SEE FIG. K0710-06A1)

SN: A80001-UP-UP

-1шт.

N/I

A/C CONDENSER KIT (SEE FIG. K0710-06A2)

SN: A80001-UP-UP

-1шт.

N/I

HEATER PIPING (SEE FIG. K0710-07A0)

SN: A80001-UP-UP

-1шт.

N/I

CONTROLLER ASSEMBLY (SEE FIG. K0710-08A1)

SN: A80001-UP-UP

-1шт.

N/I

417-963-A590

A/C HARDWARE KIT

SN: A80001-UP-UP

1шт.

|$14

306 132 C2

STRAP, TIE

SN: A80001-UP-UP

6шт.

|$15

935 522 C1

STRAP, TIE

SN: A80001-UP-UP

6шт.

|$16

01435-01025

BOLT

SN: A80001-UP-UP

5шт.

|$17

01435-01020

BOLT

SN: A80001-UP-UP

4шт.

|$18

01435-01220

BOLT

SN: A80001-UP-UP

5шт.

|$19

01435-01016

BOLT

SN: A80001-UP-UP

1шт.

|$20

08036-02514

CLIP

SN: A80001-UP-UP

1шт.

|$21

01010-81240

BOLT

SN: A80001-UP-UP

6шт.

N/I

DUCT KIT (SEE FIG. K0710-01A2)

SN: A80001-A80338-UP

-1шт.

|$24

OR

-1шт.

N/I

DUCT KIT (SEE FIG. K0710-01A3)

SN: A80339-UP-UP

-1шт.

N/I

416-963-A420

FREON, R134A

SN: A80001-UP-UP

1шт.

|$28

-1шт.

|$29

F1 - A/C AND HEATER HARDWARE KIT REPLACED BY P/N 1312 034 H91 VALVE KIT S/N A80339-UP. (SEE FIG. K0710-07A0)

-1шт.

|$30

-1шт.
