Запчасти Komatsu WA180-3L FIG. K-A СИДЕНЬЕ ОПЕРАТОРА - ВНУТР. ЧАСТИ - ТКАНЬ COVERED КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

421-57-21020

OPERATOR'S SEAT ASSEMBLY

SN: A80001-UP-UP

1шт.

|$1

421-57-21510

SEAT ASSEMBLY

SN: A80001-UP-UP

1шт.

|$2

BS162663

UPPER ASSEMBLY

SN: A80001-UP-UP

1шт.

1

NSS

BACK COVER KIT

SN: A80001-UP-UP

1шт.

2

NSS

BACK FOAM KIT

SN: A80001-UP-UP

1шт.

3

NSS

SEAT COVER KIT

SN: A80001-UP-UP

1шт.

4

NSS

SEAT FOAM KIT

SN: A80001-UP-UP

1шт.

5

BS162032

KIT, CABLE ADJUSTMENT

SN: A80001-UP-UP

1шт.

6

BS162056

SPRING KIT

SN: A80001-UP-UP

1шт.

7

BS163368

LATCH KIT

SN: A80001-UP-UP

1шт.

8

BS164188

HANDLE KIT

SN: A80001-UP-UP

1шт.

9

BS163369

HEIGHT RISER KIT

SN: A80001-UP-UP

1шт.

10

BS157230

SUSPENSION ASSEMBLY

SN: A80001-UP-UP

1шт.

11

BS157228

DAMPER ASSEMBLY KIT

SN: A80001-UP-UP

1шт.

12

BS156737

WEIGHT ADJUSTER KIT

SN: A80001-UP-UP

1шт.

13

BS156717

STOP KIT

SN: A80001-UP-UP

1шт.

14

BS156738

BEARING KIT

SN: A80001-UP-UP

1шт.

15

BS162035

ADJUSTER KIT

SN: A80001-UP-UP

1шт.

16

BS152879

HANDLE, SLIDERAIL

SN: A80001-UP-UP

1шт.

17

BS151185

HEADREST KIT

SN: A80001-UP-UP

1шт.

18

BS165216

ARMREST KIT, L.H.

SN: A80001-UP-UP

1шт.

19

BS166386

ARMREST KIT, R.H.

SN: A80001-UP-UP

1шт.
