Запчасти Komatsu WA180-3L FIG. A-A БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6736-21-1100

BLOCK ASSEMBLY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6732-21-1411

BUSHING

1шт.

3

6732-21-1611

BOLT - M14-2.00 X 119

14шт.

4

6732-21-1260

CAP, MAIN BEARING - SEMI-FINISHED

7шт.

5

6736-21-1810

PLUG, EXPANSION

6шт.

6

6732-21-1820

PLUG, EXPANSION - 1 IN.

4шт.

7

6732-21-1810

PLUG, EXPANSION - 17.73 MM

3шт.

8

6732-21-1910

DOWEL, RING - M18 X 10

14шт.

|$9

6136-01-2110

KIT, BLOCK HARDWARE

1шт.

9

6732-21-6140

DOWEL, RING - M16 X 10

2шт.

10

6732-21-1190

NOZZLE, PISTON COOLING

6шт.

11

6732-21-6130

PLUG, WELCH

1шт.

12

6732-21-6120

PIN DOWEL - M10 X 16

2шт.

13

6732-11-1910

PLUG, PIPE - 1/2 NPT

1шт.

14

6732-11-1920

PLUG, PIPE - 1/8 NPT

2шт.

N/I

6732-21-1930

O-RING

1шт.

15

6735-21-5530

PLUG, EXPANSION - NOT USED ON TURBOCHARGED ENGINES

1шт.

16

6732-21-1910

DOWEL, RING - M18 X 10

2шт.

17

6732-21-5530

PLUG, EXPANSION

1шт.

18

6732-21-6160

PLUG, EXPANSION - NOT USED WITH SIDE OIL FILL

1шт.

N/I

6732-21-1930

SEAL, O-RING

1шт.

|$22

-1шт.

|$23

SERVICE PARTS

-1шт.

|$24

-1шт.

2

6736-29-1411

BUSHING, O/S - NO. 1 BORE

-2шт.

2

6736-29-1420

BUSHING, O/S - NO. 2-5 BORE

-2шт.

4

6732-21-1260

CAP, MAIN BEARING - SEMI-FINISHED

7шт.

19

6736-29-2110

SLEEVE, SALVAGE - STD BORE

-2шт.

|$29

-1шт.

|$31

-1шт.
