Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
714-11-10003
TRANSMISSION ASS'Y
SN: (68569)-UP
1шт.
|$6
714-11-10002
TRANSMISSION ASS'Y
SN: 53001-(68568)
1шт.
|$7
714-11-10043
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: (68573)-UP
1шт.
|$8
714-11-10042
TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)
SN: 53001-(68572)
1шт.
|$$6
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.
-1шт.
|$12
714-11-12010
CLUTCH ASS'Y,REVERSE AND 1ST
SN: 53001-UP
1шт.
|$13
714-11-12110
SHAFT ASS'Y
SN: 53001-UP
1шт.
1
0
SHAFT
SN: 53001-UP
1шт.
2
0
HOUSING ASS'Y
SN: 53001-UP
1шт.
3
714-11-12650
PISTON,REVERSE
SN: 53001-UP
1шт.
4
714-11-12660
PISTON,1ST
SN: 53001-UP
1шт.
7
0
SPRING,WAVE
SN: (53001-(170423))
14шт.
8
714-08-12610
PLATE,END
SN: 53001-UP
2шт.
9
714-08-19510
RING,SNAP
SN: 53001-UP
2шт.
11
714-11-19240
RING,SEAL
SN: 53001-UP
1шт.
16
714-11-12410
GEAR, 45 TEETH,REVERSE
SN: 53001-UP
1шт.
Выбрано товаров: 29
