1
417-46-11711
FRAME, FRONT
1шт.
|$1
417-877-A110
FRAME, FRONT
1шт.
|$2
417-T80-A000
FRAME, FRONT
1шт.
2
07020-00900
FITTING, GREASE (UPPER HINGE)
1шт.
3
418-46-11150
BEARING, UPPER HINGE
1шт.
4
418-46-11320
SHIM, 0.1mm (UPPER HINGE)
4шт.
|$6
418-46-11210
SHIM, 0.2mm
2шт.
|$7
418-46-11220
SHIM, 0.5mm
4шт.
5
418-46-11180
RETAINER, UPPER HINGE
1шт.
6
01010-51030
BOLT, UPPER HINGE RETAINER
6шт.
7
01643-31032
WASHER
6шт.
8
419-09-11110
SEAL, DUST (UPPER HINGE)
2шт.
9
418-46-11160
SPACER, UPPER HINGE
2шт.
10
418-46-11141
PIN, UPPER HINGE
1шт.
11
418-46-11240
SHIM, 0.1mm (UPPER HINGE PIN)
4шт.
|$15
418-46-11250
SHIM, 0.2mm
4шт.
|$16
418-46-11260
SHIM, 0.5mm
2шт.
|$17
418-46-11270
SHIM, 1.0mm
4шт.
12
01010-51235
BOLT, UPPER HINGE PIN
4шт.
13
01643-31232
WASHER
4шт.
14
418-46-11290
NUT, LOCKING - UPPER HINGE PIN
1шт.
15
418-46-11280
WASHER
1шт.
16
417-46-11250
BEARING, ROLLER (LOWER HINGE)
1шт.
17
417-46-11260
RING, SNAP (LOWER HINGE)
2шт.
18
417-46-11270
WASHER
1шт.
19
417-46-11240
PIN, LOWER HINGE
1шт.
20
07020-00900
FITTING, GREASE (LOWER HINGE)
1шт.
21
424-46-11130
BUSHING, LOWER HINGE
1шт.
22
01010-31230
BOLT, LOWER HINGE PIN
1шт.
23
01643-31232
WASHER
1шт.
24
07020-00675
FITTING, GREASE (STEERING CYLINDER)
2шт.
25
07020-00900
FITTING, GREASE (STEERING CYLINDER)
2шт.
26
419-09-11120
SEAL, DUST (STEERING CYLINDER)
8шт.
27
417-46-12250
SPACER (STEERING CYLINDER)
2шт.
28
419-46-12280
SHIM, 1.0mm (STEERING CYLINDER)
8шт.
|$35
419-46-12290
SHIM, 0.5mm
4шт.
29
419-46-12240
PIN, MOUNT STEERING CYLINDER (FRONT)
a
2шт.
|$37
418-46-A1210
PIN, MOUNT STEERING CYLINDER (FRONT)
b
2шт.
30
419-46-12260
PIN, MOUNT STEERING CYLINDER (REAR)
a
2шт.
|$39
418-46-A1230
PIN, MOUNT STEERING CYLINDER (REAR)
b
2шт.
31
01010-51220
BOLT, CYLINDER MOUNTING PINS
4шт.
32
175-54-34170
WASHER
4шт.
33
417-46-11310
COVER, FRONT ACCESS
1шт.
|$43
416-877-1620
COVER, FRONT ACCESS
1шт.
|$44
416-879-1540
COVER, FRONT ACCESS
1шт.
34
01010-31230
BOLT, MOUNT ACCESS COVER
4шт.
35
01643-31232
WASHER
4шт.
36
01011-32470
BOLT, MOUNT FRONT AXLE
8шт.
37
01643-32460
WASHER
16шт.
38
01580-02419
NUT
8шт.
39
416-46-11210
BUMPER
2шт.
40
01010-51225
BOLT, MOUNT BUMPER
2шт.
41
01643-31232
WASHER
2шт.
|$62
-1шт.
|$54
F1 - FOR MACHINES NOT EQUIPPED WITH FRONT HYDRAULIC
-1шт.
|$55
ATTACHMENT.
-1шт.
|$63
-1шт.
|$57
F2 - FOR MACHINES EQUIPPED WITH FRONT HYDRAULIC
-1шт.
|$58
ATTACHMENT.
-1шт.
|$64
-1шт.
|$60
F3 - FOR MACHINES EQUIPPED WITH PARALLEL TOOL CARRIER
-1шт.
|$61
ATTACHMENT.
-1шт.
