Запчасти Komatsu WA180-1LC ТРАНСМИССИЯ (2 МУФТА) ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$0

417-15-13301

CLUTCH ASSEMBLY, 2nd AND 3rd

1шт.

|$1

417-15-13311

SHAFT AND HOUSING ASSEMBLY

1шт.

1

NSS

SHAFT, 2nd AND 3rd

1шт.

2

NSS

HOUSING, 2nd AND 3rd

1шт.

3

419-15-12210

RING, SEAL - 2nd HOUSING

1шт.

4

419-15-13191

PISTON

1шт.

5

419-15-12580

RING, SEAL - 2nd PISTON

1шт.

6

419-15-12290

DISC

7шт.

7

419-15-12310

PLATE, SEPARATE

8шт.

8

419-15-12133

SPRING, WAVE

7шт.

9

419-15-12281

PLATE, END

1шт.

10

419-15-12140

RING, SNAP

1шт.

11

419-15-12680

WASHER, THRUST

4шт.

12

419-15-12670

BEARING, THRUST

2шт.

13

417-15-13222

GEAR, 2nd

1шт.

14

419-15-13150

BEARING

1шт.

15

417-15-13242

GEAR

1шт.

16

06030-06312

BEARING

1шт.

17

419-15-12750

PLUG

1шт.

18

419-15-12121

RING, SEAL - 2nd AND 3rd SHAFT

3шт.

|$20

TRANSMISSION SERVICE KIT (SEE PG 02-048)

-29шт.

|$23

-1шт.

|$22

F1 - INCLUDED IN SERVICE KIT 416-15-05121.

-1шт.

|$24

-1шт.
